EUBS210TN
ELDON
1
Disponível Envio hoje
Suporte barramento 2x10 TN EUBS210TN
Suporte de barras 2x10 TN, 1/2 barras por fase, espessura 10mm, até 4500A
This busbar support, EUBS, is available for one, two, or three bars up to 120 x 10 mm. The support can be mounted either at the top or bottom of the enclosure. It is available off the shelf and tested according to IEC 61439. This support is required when a high level of mounting flexibility is required.
Sistemas de distribuição de energia / switches > Acessórios para barras coletoras
Distribución eléctrica
* Produto novo em sua embalagem original com todas as garantias e certificações de ELDON
Obrigado pelo seu interesse nos nossos artigos, esperamos que o prazo indicado seja conveniente para si.
Durante a preparação do pedido pode seleccionar o tipo de envío que melhor se adapte ás suas necessidades: Aéreo Express 24Hrs, Terrestre Standard 48/72Hrs, etc.
Descrição: | Busbar support up to 4500A to be mounted horizontally or vertically. Mounts directly to the enclosure frame or with help of CLPF profiles. Available in one/two/three bars per phase for bar thickness 10 mm, and width from 30 to 120 mm. |
Temperatura de funcionamento: | -40ºC up to 130ºC. |
Material: | Reinforced polyamide and steel. Halogen free. |
Fornecimento: | Busbar support with mounting material. |
Feature: | Horizontal main busbar support for 1, 2 or 3 bars up to 120 x 10 mm, which can be mounted either at the top or bottom of the enclosure. |
Advantage: | The standard supports are available off the shelf and have been tested according to IEC 61439. The supports are suitable for the most common bars on the market and can be mounted in enclosures with different depths, without the need for additional accessories. |
Benefit: | A flexible and reliable solution with a short delivery time, that ensures procurement, design and installation can be done efficiently reducing the labour time required. |
Comment: | The support can be mounted directly onto the enclosure's frame. |
Título: | Tamanho: | Tipo: |
---|---|---|
PDF CATÁLOGO NVENT PT.pdf | 45 Mbytes | |
EUBS210TN EUBS210TN PT_EUBS110TN.pdf | 130 Kbytes | |
Baixe o catálogo geral |
