EUBS210TN
ELDON
1
Verfügbar Schiff am heute
Unterstützung von barcode-2x10 TN, 1/2 laib phase, dicke 10mm, bis 4500A
Die Unterstützung-bar 2x10 TN, 1/2 Takte pro phase, Dicke 10mm, bis zu 4500A
This busbar support, EUBS, is available for one, two, or three bars up to 120 x 10 mm. The support can be mounted either at the top or bottom of the enclosure. It is available off the shelf and tested according to IEC 61439. This support is required when a high level of mounting flexibility is required.
Energieverteilsysteme/Schaltanlagen > Zubehör/Ersatzteile für Sammelschienen
Stromverteilung
* Neues Produkt in der Originalverpackung mit allen Garantien und Zertifizierungen von ELDON
Danke für Ihr Interesse an unseren Produkten, wir hoffen die Lieferzeit ist ok.
Während der Bestellung können Sie den für Sie bestmöglichen Versand wählen: Express 24h, Standard 48h/72h, etc.
Beschreibung: | Busbar support up to 4500A to be mounted horizontally or vertically. Mounts directly to the enclosure frame or with help of CLPF profiles. Available in one/two/three bars per phase for bar thickness 10 mm, and width from 30 to 120 mm. |
Arbeitstemperatur: | -40ºC up to 130ºC. |
Material: | Reinforced polyamide and steel. Halogen free. |
Lieferumfang: | Busbar support with mounting material. |
Feature: | Horizontal main busbar support for 1, 2 or 3 bars up to 120 x 10 mm, which can be mounted either at the top or bottom of the enclosure. |
Advantage: | The standard supports are available off the shelf and have been tested according to IEC 61439. The supports are suitable for the most common bars on the market and can be mounted in enclosures with different depths, without the need for additional accessories. |
Benefit: | A flexible and reliable solution with a short delivery time, that ensures procurement, design and installation can be done efficiently reducing the labour time required. |
Comment: | The support can be mounted directly onto the enclosure's frame. |
Titel: | Größe: | Typ: |
---|---|---|
PDF KATALOG NVENT DE.pdf | 45 Mbytes | |
EUBS210TN EUBS210TN DE_EUBS110TN.pdf | 129 Kbytes | |
Gesamtkatalog herunterladen |
