EUBS210TN
ELDON
1
Available Ship on today
Busbar support 2x10 TN EUBS210TN
Support bar 2x10 TN, 1/2 bars per phase, thickness 10mm, up to 4500A
This busbar support, EUBS, is available for one, two, or three bars up to 120 x 10 mm. The support can be mounted either at the top or bottom of the enclosure. It is available off the shelf and tested according to IEC 61439. This support is required when a high level of mounting flexibility is required.
Energy distribution systems > Accessories/spare parts for busbars
Power and distribution
* Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Description: | Busbar support up to 4500A to be mounted horizontally or vertically. Mounts directly to the enclosure frame or with help of CLPF profiles. Available in one/two/three bars per phase for bar thickness 10 mm, and width from 30 to 120 mm. |
Working temperature: | -40ºC up to 130ºC. |
Material: | Reinforced polyamide and steel. Halogen free. |
Delivery: | Busbar support with mounting material. |
Feature: | Horizontal main busbar support for 1, 2 or 3 bars up to 120 x 10 mm, which can be mounted either at the top or bottom of the enclosure. |
Advantage: | The standard supports are available off the shelf and have been tested according to IEC 61439. The supports are suitable for the most common bars on the market and can be mounted in enclosures with different depths, without the need for additional accessories. |
Benefit: | A flexible and reliable solution with a short delivery time, that ensures procurement, design and installation can be done efficiently reducing the labour time required. |
Comment: | The support can be mounted directly onto the enclosure's frame. |
Title: | Size: | Type: |
---|---|---|
PDF CATALOGUE NVENT EN.pdf | 76 Mbytes | |
EUBS210TN EUBS210TN EN_EUBS110TN.pdf | 123 Kbytes | |
