SPTA 1/ 3-5,0 BD2:S1-S3 1716497 PHOENIX CONTACT Terminal for printed circuit board
SPTA 1/ 3-5,0 BD2:S1-S3
1716497
PHOENIX_CONTACT
100
Terminal for printed circuit board
Terminal block for printed circuit board, nominal current: 9 A, nominal voltage (III/2): 320 V, nominal cross-section: 1 mm², number of potentials: 3, number of rows: 1, number of poles per row: 3, article family: SPTA 1/, pitch: 5 mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 65 °, color: green, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.5 mm, number of welding pins per potential: 1, packaging type: boxed
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Terminal for printed circuit board, rated current: 9, rated voltage: 320 V, pitch: 5 mm, number of poles: 3, connection type: spring clamp push-in, mounting: Soldering by wave direction for connection conductor/pcb: 65 °, color: green
Data commercial
| Key order | One million seven hundred sixteen thousand four hundred ninety seven |
|---|---|
| Packing unit | 100 pcs |
| Key selling | AAABBA - |
| Minimum order quantity | 100 pcs |
| EAN | Four trillion fifty five billion six hundred twenty six million four hundred fifty six thousand one hundred two |
| Unit weight (excluding packaging) | 1,780 g |
| Tariff number tariff | Eighty five million three hundred sixty nine thousand ten |
Properties of the article
| Abbreviation | Terminal for printed circuit board |
|---|---|
| Family of articles | SPTA 1/ |
| Step | 5 mm |
| Number of poles | Three |
| Type of connection | Connection by spring loaded push-in |
| Mounting type | Wave soldering |
| Design of the pin | Available pin linear |
| Number of floors | One |
| Number of connections | Three |
| Number of potential | Three |
Characteristic data electrical
| Rated | 9 To |
|---|---|
| Voltage isolation design (III/2) | 320 V |
| Transient voltage design (III/2) | 4 kV |
Ability conex.
| Section of conductor rigid | 0,2 mm2 ... 1.5 mm2 |
|---|---|
| Section of flexible conductor | 0,2 mm2 ... 1.5 mm2 |
| Section of conductor AWG / kcmil | 24 ... 16 |
| Section of flexible conductor with toe cap, without plastic sleeve | 0.25 mm2 ... 0.75 mm2 |
| Section of flexible conductor with toe, with padded insulation | 0.25 mm2 ... 0.75 mm2 |
| Length of peeling | 8 mm |
Material data - contact
| Observation | According to WEEE/RoHS, without filaments according to IEC 60068-2-82/JEDEC JESD 201 |
|---|---|
| Material contact | Cu alloy |
| Metal surface of the point of embornaje (top layer) | Tin (4 - 8 ám Sn) |
| Metal surface area of solder (upper layer) | Tin (4 - 8 ám Sn) |
Material data - housing
| Isolation | PA |
|---|---|
| Group insulating material | I |
| CTI according to IEC 60112 | Six hundred |
| Class of flammability according to UL 94 | V0 |
| Number of flammability of filaments GWFI according to en 60695-2-12 | Eight hundred fifty |
| Ignition temperature of filaments GWIT according to en 60695-2-13 | Seven hundred seventy five |
| Temperature test of the hardness for the balls according to en 60695-10-2 | 125 °C |
Product dimensions
| Outline dimensions | |
|---|---|
| Length [ l ] | 10 mm |
| Width [ w ] | 14.1 mm |
| Height [ h ] | 15.9 mm |
| Step | 5 mm |
| Height of building (height without the shank of soldering) | 12,4 mm |
| Length of pin [P] | 3.5 mm |
| Separation between rods | 5 mm |
| Dimensions of pin | 0.6 x 1 mm |
| Average | 10 mm |
Dimensions for the design of the printed circuit board
| Diameter hole | 1.1 mm |
|---|---|
| Separation between rods | 5 mm |
Indications of packing
| Type of packaging | packaged in box |
|---|---|
| Packing unit | One hundred |
| Designation packing Units | Units |
Electrical testing
| Rated | 9 To |
|---|---|
| Voltage isolation design (III/2) | 320 V |
| Transient voltage design (III/2) | 4 kV |
Lines of flight and air spaces
| Group insulating material | I |
|---|---|
| Voltage isolation design (III/3) | 250 V |
| Voltage isolation design (III/2) | 320 V |
| Voltage isolation design (II/2) | 630 V |
| Transient voltage design (III/3) | 4 kV |
| Transient voltage design (III/2) | 4 kV |
| Transient voltage design (II/2) | 4 kV |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss
| eCl@ss 5.1 | Twenty seven million two hundred sixty one thousand one hundred |
|---|---|
| eCl@ss 6.0 | Twenty seven million two hundred sixty one thousand one hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand four hundred one |
ETIM
| ETIM 5.0 | EC002643 |
|---|---|
| ETIM 6.0 | EC002643 |
| ETIM 7.0 | EC002643 |
| Feature Name | Feature Value |
|---|---|
| Height (EF000040) | 15.9 mm |
| Number of electrical connections (EF008252) | 3 |
| Number of levels (EF002659) | 1 |
| Modular spacing connections (EF006827) | 5 mm |
| Rated current In (EF008250) | 9 A |
| Rated voltage (EF000228) | 320 V |
| Rated surge voltage (EF002993) | 4 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Connection type conductor (EF006821) | Spring clamp connection |
| Connectable conductor cross section solid-core (EF007337) | 0.2 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | 0.25 mm² |
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | 0.2 mm² |
| Connectable conductor cross section multi-wired (EF007343) | 1.5 mm² |
| Connection type PCB (EF006822) | Soldering connection |
| Material connection surface (EF006826) | Tin |
| Diameter connection pin (EF006823) | 1.1 mm |
| Length pin (EF006825) | 3.5 mm |
| Material insulation body (EF007543) | Other |
| Housing colour (EF000136) | Green |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
| Type of PCB fastening (EF008226) | Connecting contact |
| Type of fastening (EF002442) | Solder |
| Type of banding (EF007011) | Carton (for SMD) |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
