1SDA068170R1 ABB XT2H160 PART OF 4P F F INTERRUPTION
1SDA068170R1
ABB
XT2H160 PART OF 4P F F INTERRUPTION
XT2H 160 BREAKING PART 4p F F
Low-voltage industrial components > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2348 |
| Environmental Product Declaration - EPD | 9AKK108469A1856 |
| 9AKK108468A1891 | |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 55.70 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | 663e8bf8-ac39-45e2-bb3b-477786a0534a Italy |
| Simplified SCIP | 11db11de-5fe4-45c9-b5e1-9f0c228fac65 Germany |
| 9672d8a0-cbab-4eea-b1fa-0a023db90dc1 France | |
| 1daaad42-b6d2-4f63-85fe-f0ba430cdfbe Sweden | |
| 882b6139-5abd-4752-b709-d722c2a7d2b1 Germany | |
| dfb6fdb2-85f0-4fdb-8914-4f62acc0cbbc Germany | |
| d96948a6-b3be-4d26-9f1f-21268276d34a France | |
| 530e06d4-768a-4329-a9f0-9d54befb7dd1 Netherlands | |
| 907efefb-2e63-4da6-a80d-87193b914a88 Spain | |
| 1b3f7be3-1197-4c36-bef4-b19b4a9e1199 Netherlands | |
| f5ae6816-a17b-414b-83d8-ea6be56b0f48 Poland | |
| 883d3077-7100-4b9b-8a4b-ceef1e8d9006 Norway | |
| 8ab542da-9e9d-44ce-9387-737bb6954d04 Sweden | |
| 0ecfcaad-84c4-4d3a-8560-a33e692569db Poland | |
| dbb16089-1024-4a39-bc5c-653a765b66a1 Finland | |
| 7ab595e7-a807-4417-9740-52f1a338d40f Netherlands | |
| bfad18d1-cf60-4d82-8e92-11060ebc1db0 Germany | |
| 1c81d21a-a430-4295-813a-5d972026dcdd Denmark | |
| 9e7b6aea-846c-431d-b6d2-df49017ffcd7 Germany | |
| 99641427-b52a-4305-8555-ae54782cdf2f Croatia | |
| e277dcf6-d6bb-4f3a-8358-e7553b09982f Czech Republic | |
| 8c0d26f3-1080-4b69-be9d-96ef1d4d5110 Poland | |
| 96a5c325-9bd4-41a4-8dd3-3fba1bb6fcf7 Netherlands | |
| 1acc923e-fb90-4570-9e48-2ad99899dee2 Netherlands | |
| 476c31ba-afe5-489d-af9f-9df3fceff712 Estonia | |
| a81ba7ef-697e-40f5-a67f-236f7b95159c Greece | |
| bf325f2d-324a-48c8-9f9e-d7c8af2edca6 Portugal | |
| 969daf7d-2111-46a2-b7b9-f96769350334 Bulgaria | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| E-Number (Finland) | 3640555 |
| E-Number (Norway) | 4379740 |
| EAN | 8015644020675 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 120 mm |
| Product Net Height | 130 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 1.2 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 150 mm |
| Package Level 1 Height | 215 mm |
| Package Level 1 Depth / Length | 135 mm |
| Package Level 1 Gross Weight | 1.3 kg |
| Package Level 1 EAN | 8015644020675 |
| Additional Information | |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Breaking Part |
| Version | F |
| Technical | |
| Electrical Durability | 120 cycles per hour |
| 8000 cycle | |
| Mechanical Durability | 240 cycles per hour |
| 25000 cycle | |
| Number of Poles | 4P |
| Opening Time | CB with SOR 30 ms |
| CB with UVR 30 ms | |
| Order Multiple | 1 piece |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| 500 V DC | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 30 kA | |
| (690 V AC) 15 kA | |
| (250 V DC) 2 Poles in Series 70 kA | |
| (500 V DC) 3 Poles in Series 70 kA | |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 30 kA | |
| (690 V AC) 15 kA | |
| (250 V DC) 2 Poles in Series 70 kA | |
| (500 V DC) 3 Poles in Series 70 kA | |
| Rated Uninterrupted Current (Iu) | 160 A |
| Rated Voltage (Ur) | 690 V |
| Short-Circuit Performance Level | H |
| Standards | IEC60947-2 |
| Sub-type | XT2 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK106713A5901 |
| GL Certificate | 1SDL000163R0093 |
| LR Certificate | 1SDL000163R0100 |
| Instructions and Manuals | 1SDH000721R0001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| UNSPSC | 39120000 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
