Ver maior As imagens são só a título ilustrativo. Por favor, consulte a ficha técnica.

XS6W-6PUR8SS100CM-YH 682428 XS6W6PUR8SS100CMYH OMRON Ethernet patch cable Cat.6, PUR 1 m

0/5 - 0 Opiniones

Referência: XS6W-6PUR8SS100CM-YH

Código: 682428

Número de catálogo: XS6W6PUR8SS100CMYH

Fabricante: OMRON

Descrição:

Ethernet patch cable Cat.6, PUR 1 m

Mais detalhes

Categorias:

Sistemas de Controlo > Acessórios Sist. de Controlo

* Produto novo em sua embalagem original com todas as garantias e certificações de OMRON

Garantía, reparação e devolução.

* Este artigo pode estar obsoleto. Se você estiver interessado, insira seu e-mail e informaremos se há unidades disponíveis. Caso não existam mais, um dos nossos técnicos procurará uma alternativa fornecivel com características semelhantes.

Se o nosso preço não é o melhor, peça-nos uma cotação Solicitar uma cotação

PRODUTOS VISUALIZADOS

Mais informação

▲

Características

Controlador Sysmac - Série NJ5

A série NJ5 é um controlador de máquinas para sequência lógica e movimento que inclui opções de CPU para funções avançadas, tais como robótica e ligação às bases de dados.

Tempo de ciclo mais rápido: 500 µs
Número de eixos: 64, 32, 16
Núcleo de movimento sincronizado
Funções: Sequência lógica, Motion, CNC, Robótica, Ligação às bases de dados e SECS/GEM
Controlo de robôs Delta, SCARA e Cartesianos
Ligação à BD: cliente SQL para servidor SQL da Microsoft, Oracle, IBM DB2, MySQL, Firebird
Funcionalidade de CNC: Ideal para tornos, máquinas fresadoras ou corte XY, bem como qualquer outra aplicação de seguimento de percurso, tais como máquinas de distribuição, quinagem, desbaste e moldagem
Capacidade para efectuar múltiplas tarefas
Portas EtherCAT e EtherNet/IP incorporadas

Ordering information

NJ series system

NJ series expansion racks

Power supply units

Symbol	Name	Output capacity			RUN output	Order code
Symbol	Name	5 VDC	24 VDC	Total	RUN output	Order code
①	100 to 240 VAC power supply unit for NJ CPU	6.0 A	1.0 A	30 W	Supported	NJ-PA3001
①	24 VDC power supply unit for NJ CPU	6.0 A	1.0 A	30 W	Supported	NJ-PD3001

Note:Power supply units for the CJ Series cannot be used as a power supply for a CPU rack of the NJ System or as a power supply for an expansion rack.

NJ5 series CPU units

Symbol	CPU	Program capacity	Variables capacity	Specifications	Functionalities						Number of axes	Order code
Symbol	CPU	Program capacity	Variables capacity	Specifications	Sequence	Motion	OPC UA	DB connection	Robotics	CNC	Number of axes	Order code
②	NJ501	20 MB	2 MB: Retained 4 MB: Not retained	I/O capacity: 2,560 points CPU rack: 10 units max. Expansion rack: 10 units max. (Up to 3 expansion racks) 40 units max. per system (CPU rack + 3 expansion racks) Current consumption: 1.90 A at 5 VDC	⬛	⬛	⬛				64	NJ501-1500
					⬛	⬛	⬛				32	NJ501-1400
					⬛	⬛	⬛				16	NJ501-1300
					⬛	⬛		⬛			64	NJ501-1520
					⬛	⬛		⬛			32	NJ501-1420
					⬛	⬛		⬛			16	NJ501-1320
					⬛	⬛		⬛	⬛		16	NJ501-4320
					⬛	⬛			⬛		64	NJ501-4500
					⬛	⬛			⬛		32	NJ501-4400
					⬛	⬛			⬛		16	NJ501-4300
					⬛	⬛			⬛		16	NJ501-4310
					⬛	⬛				⬛	16	NJ501-5300

Note:The end cover unit CJ1W-TER01 is included with the CPU unit.

CJ series digital I/O units

Symbol	Points	Type	Rated voltage	Rated current	Width	Remarks	Current consumption (A)		Connection type	Order code
Symbol	Points	Type	Rated voltage	Rated current	Width	Remarks	5 VDC	24 VDC	Connection type	Order code
③	8	AC input	240 VAC	10 mA	31 mm	-	0.08	-	M3	CJ1W-IA201
	16	AC input	120 VAC	7 mA	31 mm	-	0.09	-	M3	CJ1W-IA111
	8	DC input	24 VDC	10 mA	31 mm	-	0.08	-	M3	CJ1W-ID201
	16		24 VDC	7 mA	31 mm	-	0.08	-	M3	CJ1W-ID211
	16		24 VDC	7 mA	31 mm	-	0.08	-	Screwless	CJ1W-ID211(SL)
	16		24 VDC	7 mA	31 mm	Fast-response (15μs is ON, 90μs is OFF)	0.13	-	M3	CJ1W-ID212
	16		24 VDC	7 mA	31 mm	Inputs start interrupt tasks in PLC program	0.08	-	M3	CJ1W-INT01
	16		24 VDC	7 mA	31 mm	Latches pulses down to 50μs pulse width	0.08	-	M3	CJ1W-IDP01
	32		24 VDC	4.1 mA	20 mm	-	0.09	-	Fujitsu	CJ1W-ID231
	32		24 VDC	4.1 mA	20 mm	-	0.09	-	MIL	CJ1W-ID232
	32		24 VDC	4.1 mA	20 mm	Fast-response (15μs is ON, 90μs is OFF)	0.20	-	MIL	CJ1W-ID233
	64		24 VDC	4.1 mA	31 mm	-	0.09	-	Fujitsu	CJ1W-ID261
	64		24 VDC	4.1 mA	31 mm	-	0.09	-	MIL	CJ1W-ID262
	8	Triac output	250 VAC	0.6 mA	31 mm	-	0.22	-	M3	CJ1W-OA201
	8	Relay contact output	250 VAC	2 A	31 mm	-	0.09	0.048	M3	CJ1W-OC201
	8		250 VAC	2 A	31 mm	-	0.09	0.048	Screwless	CJ1W-OC201(SL)
	16		250 VAC	2 A	31 mm	-	0.11	0.096	M3	CJ1W-OC211
	16		250 VAC	2 A	31 mm	-	0.11	0.096	Screwless	CJ1W-OC211(SL)
	8	DC output (sink)	12 to 24 VDC	2 A	31 mm	-	0.09	-	M3	CJ1W-OD201
	8		12 to 24 VDC	0.5 A	31 mm	-	0.10	-	M3	CJ1W-OD203
	16		12 to 24 VDC	0.5 A	31 mm	-	0.10	-	M3	CJ1W-OD211
	16		12 to 24 VDC	0.5 A	31 mm	-	0.10	-	Screwless	CJ1W-OD211(SL)
	16		24 VDC	0.5 A	31 mm	Fast-response (15μs is ON, 80μs is OFF)	0.15	-	M3	CJ1W-OD213
	32		12 to 24 VDC	0.5 A	20 mm	-	0.14	-	Fujitsu	CJ1W-OD231
	32		12 to 24 VDC	0.5 A	20 mm	-	0.14	-	MIL	CJ1W-OD233
	32		24 VDC	0.5 A	20 mm	Fast-response (15μs is ON, 80μs is OFF)	0.22	-	MIL	CJ1W-OD234
	64		12 to 24 VDC	0.3 A	31 mm	-	0.17	-	Fujitsu	CJ1W-OD261
	64		12 to 24 VDC	0.3 A	31 mm	-	0.17	-	MIL	CJ1W-OD263
	8	DC output (source)	24 VDC	2 A	31 mm	Short-circuit protection	0.11	-	M3	CJ1W-OD202
	8		24 VDC	0.5 A	31 mm	Short-circuit protection	0.10	-	M3	CJ1W-OD204
	16		24 VDC	0.5 A	31 mm	Short-circuit protection	0.10	-	M3	CJ1W-OD212
	16		24 VDC	0.5 A	31 mm	Short-circuit protection	0.10	-	Screwless	CJ1W-OD212(SL)
	32		24 VDC	0.3 A	20 mm	Short-circuit protection	0.15	-	MIL	CJ1W-OD232
	64		24 VDC	0.3 A	31 mm	-	0.17	-	MIL	CJ1W-OD262
	16 + 16	DC in + out (source)	24 VDC	0.5 A	31 mm	-	0.13	-	MIL	CJ1W-MD232
	16 + 16	DC in + out (sink)	24 VDC	0.5 A	31 mm	-	0.13	-	Fujitsu	CJ1W-MD231
	16 + 16		24 VDC	0.5 A	31 mm	-	0.13	-	MIL	CJ1W-MD233
	32 + 32		24 VDC	0.3 A	31 mm	-	0.14	-	Fujitsu	CJ1W-MD261
	32 + 32		24 VDC	0.3 A	31 mm	-	0.14	-	MIL	CJ1W-MD263
	32 + 32	DC in + out (TTL)	5 VDC	35 mA	31 mm	-	0.19	-	MIL	CJ1W-MD563

Note:MIL = Connector according to MIL-C-83503 (compatible with DIN 41651/IEC 60603-1).

CJ series analog I/O and control units

Symbol	Points	Type	Ranges	Resolution	Accuracy	Conversion time	Width	Remarks	Current (A)		Connection type	Order code
Symbol	Points	Type	Ranges	Resolution	Accuracy	Conversion time	Width	Remarks	5 V	24 V	Connection type	Order code
③	4	Universal analog input	0 to 5 V, 1 to 5 V, 0 to 10 V, 0 to 20 mA, 4 to 20 mA, K, J, T, L, R, S, B, Pt100, Pt1000, JPt100	V/l: 1/12,000 T/C: 0.1°C RTD: 0.1°C	V: 0.3% I: 0.3% T/C: 0.3% RTD: 0.3%	250 ms/4 points	31 mm	Universal inputs, with zero/span adjustment, configurable alarms, scaling, sensor error detection	0.32	-	M3	CJ1W-AD04U
	4	Universal analog input		V/l: 1/12,000 T/C: 0.1°C RTD: 0.1°C	V: 0.3% I: 0.3% T/C: 0.3% RTD: 0.3%	250 ms/4 points	31 mm		0.32	-	Screwless	CJ1W-AD04U(SL)
	4	Analog input	0 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/8,000	V: 0.2% I: 0.4%	250μs/point	31 mm	Offset/gain adjustment, peak hold, moving average, alarms	0.42	-	M3	CJ1W-AD041-V1
	4	Analog input	0 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/8,000	V: 0.2% I: 0.4%	250μs/point	31 mm	Offset/gain adjustment, peak hold, moving average, alarms	0.42	-	Screwless	CJ1W-AD041-V1(SL)
	4	High-speed analog input	1 to 5 V, 0 to 10 V, -5 to 5 V, -10 to 10 V, 4 to 20 mA	1/40,000	V: 0.2% I: 0.4%	35μs/4 points	31 mm	Direct conversion (CJ2H special instruction)	0.52	-	M3	CJ1W-AD042
	8	Analog input	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/8,000	V: 0.2% I: 0.4%	250μs/point	31 mm	Offset/gain adjustment, peak hold, moving average, alarms	0.42	-	M3	CJ1W-AD081-V1
	8	Analog input	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/8,000	V: 0.2% I: 0.4%	250μs/point	31 mm	Offset/gain adjustment, peak hold, moving average, alarms	0.42	-	Screwless	CJ1W-AD081-V1(SL)
	2	Analog output	0 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/4,000	V: 0.3% I: 0.5%	1 ms/point	31 mm	Offset/gain adjustment, output hold	0.12	0.14	M3	CJ1W-DA021
	2	Analog output	0 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/4,000	V: 0.3% I: 0.5%	1 ms/point	31 mm	Offset/gain adjustment, output hold	0.12	0.14	Screwless	CJ1W-DA021(SL)
	4	Analog output	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/4,000	V: 0.3% I: 0.5%	1 ms/point	31 mm	Offset/gain adjustment, output hold	0.12	0.2	M3	CJ1W-DA041
	4	Analog output	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/4,000	V: 0.3% I: 0.5%	1 ms/point	31 mm	Offset/gain adjustment, output hold	0.12	0.2	Screwless	CJ1W-DA041(SL)
	4	High-speed analog output	1 to 5 V, 0 to 10 V, -10 to 10 V	1/40,000	0.3%	35μs/4 points	31 mm	Direct conversion (CJ2H special instruction)	0.40	-	M3	CJ1W-DA042V
	8	Voltage output	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V	1/8,000	0.3%	250μs/point	31 mm	Offset/gain adjustment, output hold	0.14	0.14	M3	CJ1W-DA08V
	8	Voltage output	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V	1/8,000	0.3%	250μs/point	31 mm	Offset/gain adjustment, output hold	0.14	0.14	Screwless	CJ1W-DA08V(SL)
	8	Current output	4 to 20 mA	1/8,000	0.5%	250μs/point	31 mm	Offset/gain adjustment, output hold	0.14	0.17	M3	CJ1W-DA08C
	8	Current output	4 to 20 mA	1/8,000	0.5%	250μs/point	31 mm	Offset/gain adjustment, output hold	0.14	0.17	Screwless	CJ1W-DA08C(SL)
	4 + 2	Analog in + out	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/8,000	in: 0.2% out: 0.3%	1 ms/point	31 mm	Offset/gain adjustment, scaling, peak hold, moving average, alarms, output hold	0.58	-	M3	CJ1W-MAD42
	4 + 2	Analog in + out	1 to 5 V, 0 to 10 V, -10 to 10 V, 1 to 5 V, 4 to 20 mA	1/8,000	in: 0.2% out: 0.3%	1 ms/point	31 mm		0.58	-	Screwless	CJ1W-MAD42(SL)
	4	Universal analog input	DC voltage, DC current, thermocouple, Pt100/Pt1000, potentiometer	1/256,000	0.05%	60 ms/4 points	31 mm	All inputs individually isolated, configurable alarms, maintenance functions, user-defined scaling, zero/span adjustment	0.30	-	M3	CJ1W-PH41U
	2	Process input	4 to 20 mA, 0 to 20 mA, 0 to 10 V, -10 to 10 V, 0 to 5 V, -5 to 5 V, 1 to 5 V, 0 to 1.25 V, 1.25 to 1.25 V	1/64,000	0.05%	5 ms/point	31 mm	Configurable alarms, maintenance functions, user-defined scaling, zero/span adjustment, square root, totaliser	0.18	0.09	M3	CJ1W-PDC15
	6	Temperature control loops, thermocouple	K-type (-200 to 1,300°C) J-type (-100 to 850ºC)	0.1°C	0.5%	40 ms/point	31 mm	Basic I/O unit, setup by DIP switches, adjustable filtering 10/50/60 Hz	0.22	-	M3	CJ1W-TS561
	6	Temperature control loops, thermocouple	K-type (-200 to 1,300°C) J-type (-100 to 850ºC)	0.1°C	0.5%	40 ms/point	31 mm		0.22	-	Screwless	CJ1W-TS561(SL)
	6	Temperature control loops	Pt100 (-200 to 650°C) Pt1000 (-200 to 650°C)	0.1°C	0.5%	40 ms/point	31 mm	Basic I/O unit, setup by DIP switches, adjustable filtering 10/50/60 Hz	0.25	-	M3	CJ1W-TS562
	6	Temperature control loops	Pt100 (-200 to 650°C) Pt1000 (-200 to 650°C)	0.1°C	0.5%	40 ms/point	31 mm		0.25	-	Screwless	CJ1W-TS562(SL)
	2	Temperature control loops, thermocouple	B, J, K, L, R, S, T	0.1°C	0.3%	500 ms total	31 mm	Open collector NPN outputs	0.25	-	M3	CJ1W-TC003
	2	Temperature control loops, thermocouple	B, J, K, L, R, S, T	0.1°C	0.3%	500 ms total	31 mm	Open collector PNP outputs	0.25	-	M3	CJ1W-TC004
	2	Temperature control loops	Pt100, JPt100	0.1°C	0.3%	500 ms total	31 mm	Open collector NPN outputs	0.25	-	M3	CJ1W-TC103
	2	Temperature control loops	Pt100, JPt100	0.1°C	0.3%	500 ms total	31 mm	Open collector PNP outputs	0.25	-	M3	CJ1W-TC104

CJ series special I/O units

Symbol	Channels	Type	Signal type	Width	Remarks	Current consumption (A)		Connection type	Order code
Symbol	Channels	Type	Signal type	Width	Remarks	5 V	24 V	Connection type	Order code
③	2	500 kHz Counter	24 V, line driver	31 mm	2 configurable digital inputs + outputs	0.28	-	Fujitsu	CJ1W-CT021
	2	500 kHz Counter	24 V, line driver		2 configurable digital inputs + outputs	0.28	-	Fujitsu	CJ1W-CT021	4	100 kHz Counter	Line driver, 24 V via terminal block	Target values trigger interrupt to CPU	0.32	-	1 × MIL (40 pt)	CJ1W-CTL41-E

CJ series communication units

Symbol	Type	Ports	Data transfer	Protocols	Width	Current consumption (A)		Connection type	Order code
Symbol	Type	Ports	Data transfer	Protocols	Width	5 V	24 V	Connection type	Order code
③	Serial communications units	2 × RS-232C	High-speed	CompoWay/F, host link, NT link, Modbus, user-defined	31 mm	0.28	-	9 pin D-Sub	CJ1W-SCU22
		2 × RS-232C			31 mm	0.28	-	9 pin D-Sub	CJ1W-SCU22	2 × RS-422A/RS-485	31 mm	0.28	-	9 pin D-Sub	CJ1W-SCU32
		1 × RS-232C + 1 × RS-422/RS-485			31 mm	0.28	-	9 pin D-Sub	CJ1W-SCU42
		EtherNet/IP			1 × 100 Base-Tx	-	EtherNet/IP, UDP, TCP/IP, FTP server, SNTP, SNMP	31 mm	0.41	-	RJ45	CJ1W-EIP21
	EtherCAT	2 × 100 Base-Tx	-	EtherCAT	31 mm	0.34	-	RJ45	CJ1W-ECT21
	DeviceNet	1 × CAN	-	DeviceNet	31 mm	0.29	-	5-p detachable	CJ1W-DRM21
	CompoNet	4-wire, data + power to slaves (Master)	-	CompoNet (CIP-based)	31 mm	0.4	-	4-p detachable IDC or screw	CJ1W-CRM21
	PROFIBUS-DP	1 × RS-485 (Master)	-	DP, DPV1	31 mm	0.40	-	9 pin D-Sub	CJ1W-PRM21
	PROFIBUS-DP	1 × RS-485 (Slave)	-	DP	31 mm	0.40	-	9 pin D-Sub	CJ1W-PRT21
	PROFINET-IO	1 × 100 Base-Tx	-	PROFINET-IO controller, FINS/UDP	31 mm	0.42	-	RJ45	CJ1W-PNT21
	RS-422A converter accessory	RS-232C to RS-422A/RS-485 signal converter. Mounts directly on serial port						9 pin D-Sub to screw clamp terminals	CJ1W-CIF11

CJ series ID sensor units

Symbol	Type	Specifications				Current consumption (A)		Order code
		Connected ID systems	No. of connected R/W heads	External power supply	No. of unit numbers allocated	Current consumption (A)
		Connected ID systems	No. of connected R/W heads	External power supply	No. of unit numbers allocated	5 V	24 V
③	ID sensor units	V680-Series RFID system	1	Not required	1	0.26	0.13	CJ1W-V680C11
③	ID sensor units	V680-Series RFID system	2	Not required	2	0.32	0.26	CJ1W-V680C12

Note:The data transfer function using intelligent I/O commands can not be used.

Expansion racks

CJ series I/O control unit (mounted on CPU rack when connecting expansion racks)

Symbol	Name	Connecting cable	Connected Unit	Width	Current consumption (A)		Order code
Symbol	Name	Connecting cable	Connected Unit	Width	5 V	24 V	Order code
④	CJ-Series I/O control unit	CS1W-CN__3	CJ1W-II101	20 mm	0.02 A	-	CJ1W-IC101

Note:Mount to the right of the power supply unit.

CJ series I/O interface unit (mounted on expansion rack)

Symbol	Name	Connecting cable	Width	Current consumption (A)		Order code
Symbol	Name	Connecting cable	Width	5 V	24 V	Order code
⑤	CJ-Series I/O interface unit	CS1W-CN__3	31 mm	0.13 A	-	CJ1W-II101

Note:Mount to the right of the power supply unit.

I/O connecting cables

Symbol	Name	Specifications	Order code
Symbol	Name	Specifications	Order code	⑥	I/O connecting cable	Connects an I/O control unit on NJ series CPU rack to an I/O interface unit on a NJ series expansion rack. or Connects an I/O interface unit on NJ series expansion rack to an I/O interface unit on another NJ series expansion rack.	Cable length: 0.3 m	CS1W-CN313
Cable length: 0.7 m	CS1W-CN713
Cable length: 2 m	CS1W-CN223
Cable length: 3 m	CS1W-CN323
Cable length: 5 m	CS1W-CN523
Cable length: 10 m	CS1W-CN133
Cable length: 12 m	CS1W-CN133-B2

EtherCAT junction slave

Symbol	Appearance	Name	No. of ports	Power supply voltage	Current consumption (A)	Dimensions (W × D × H)	Weight	Order code
⑦		EtherCAT junction slave	3	20.4 to 28.8 VDC (24 VDC -15 to 20%)	0.08	25 mm × 78 mm × 90 mm	165 g	GX-JC03
	6	0.17	48 mm × 78 mm × 90 mm	220 g	GX-JC06

Symbol

Appearance

Name

No. of ports

Power supply voltage

Current

consumption (A)

Dimensions (W × D × H)

Weight

Order code

⑦

EtherCAT junction slave

20.4 to 28.8 VDC

(24 VDC -15 to 20%)

0.08

25 mm × 78 mm × 90 mm

165 g

GX-JC03

0.17

48 mm × 78 mm × 90 mm

220 g

GX-JC06

Note1.Please do not connect EtherCAT junction slave with OMRON position control unit, Model CJ1W-NC_81/_82.
2.EtherCAT junction slave cannot be used for Ethernet/IP and Ethernet.

Industrial switching hubs

Symbol	Appearance	Specifications			Accessories	Current consumption (A)	Order code
Symbol	Appearance	Functions	No. of ports	Failure detection	Accessories	Current consumption (A)	Order code
⑧		Quality of Service (QoS): EtherNet/IP control data priority. Failure detection: Broadcast storm and LSI error detection 10/100 BASE-TX, Auto-Negotiation	3	No	Power supply connector	0.22	W4S1-03B
			5	No	Power supply connector		W4S1-05B
			5	Yes	Power supply connector and connector for informing error		W4S1-05C

Recommended EtherCAT and EtherNet/IP communication cables

Symbol

Item

Manufacturer

Color

Cable
length (m)

Order code

⑨

EtherCAT cable

Cat 5e, AWG22, 2-pair cable

M12/Smartclick connectors

Improved shield for EtherCAT
communications

Standard type

Cable with connectors on both ends

(M12 straight/M12 straight)

OMRON

Black

0.5

XS5W-T421-BM2-SS

XS5W-T421-CM2-SS

XS5W-T421-DM2-SS

XS5W-T421-EM2-SS

XS5W-T421-GM2-SS

XS5W-T421-JM2-SS

Rugged type

Cable with connectors on both ends

(M12 straight/RJ45)

Black

0.5

XS5W-T421-BMCSS

XS5W-T421-CMC-SS

XS5W-T421-DMC-SS

XS5W-T421-EMC-SS

XS5W-T421-GMC-SS

XS5W-T421-JMC-SS

Ethernet/EtherCAT
patch cable

Cat 6a, AWG27, 4-pair cable

Cable sheath material: LSZH,

Standard type

Cable with connectors on both ends (RJ45/RJ45)

Yellow

0.2

XS6W-6LSZH8SS20CM-Y

0.3

XS6W-6LSZH8SS30CM-Y

0.5

XS6W-6LSZH8SS50CM-Y

XS6W-6LSZH8SS100CM-Y

1.5

XS6W-6LSZH8SS150CM-Y

XS6W-6LSZH8SS200CM-Y

XS6W-6LSZH8SS300CM-Y

XS6W-6LSZH8SS500CM-Y

7.5

XS6W-6LSZH8SS750CM-Y

XS6W-6LSZH8SS1000CM-Y

XS6W-6LSZH8SS1500CM-Y

XS6W-6LSZH8SS2000CM-Y

Green

0.2

XS6W-6LSZH8SS20CM-G

0.3

XS6W-6LSZH8SS30CM-G

0.5

XS6W-6LSZH8SS50CM-G

XS6W-6LSZH8SS100CM-G

1.5

XS6W-6LSZH8SS150CM-G

XS6W-6LSZH8SS200CM-G

XS6W-6LSZH8SS300CM-G

XS6W-6LSZH8SS500CM-G

7.5

XS6W-6LSZH8SS750CM-G

XS6W-6LSZH8SS1000CM-G

XS6W-6LSZH8SS1500CM-G

XS6W-6LSZH8SS2000CM-G

Cat 5e, AWG26, 4-pair cable

Cable sheath material: PUR

Standard type

Cable with connectors on both ends (RJ45/RJ45)

Green

0.5

XS6W-5PUR8SS50CM-G

XS6W-5PUR8SS100CM-G

1.5

XS6W-5PUR8SS150CM-G

XS6W-5PUR8SS200CM-G

XS6W-5PUR8SS300CM-G

XS6W-5PUR8SS500CM-G

7.5

XS6W-5PUR8SS750CM-G

XS6W-5PUR8SS1000CM-G

XS6W-5PUR8SS1500CM-G

XS6W-5PUR8SS2000CM-G

⑨

Ethernet/EtherCAT
patch cable

Cat 5e, AWG22, 2-pair cable

Rugged type

Cable with connectors on both ends (RJ45/RJ45)

OMRON

Grey

0.3

XS5W-T421-AMD-K

0.5

XS5W-T421-BMD-K

XS5W-T421-CMD-K

XS5W-T421-DMD-K

XS5W-T421-EMD-K

XS5W-T421-GMD-K

XS5W-T421-JMD-K

XS5W-T421-KMD-K

Rugged type

Cable with connectors on both ends (M12 straight/RJ45)

Grey

0.3

XS5W-T421-AMC-K

0.5

XS5W-T421-BMC-K

XS5W-T421-CMC-K

XS5W-T421-DMC-K

XS5W-T421-EMC-K

XS5W-T421-GMC-K

XS5W-T421-JMC-K

XS5W-T421-KMC-K

Cat 5e, AWG22, 2-pair cable

Rugged type

Cable with connectors on both ends (M12 L right angle/RJ45)

Grey

0.3

XS5W-T422-AMC-K

0.5

XS5W-T422-BMC-K

XS5W-T422-CMC-K

XS5W-T422-DMC-K

XS5W-T422-EMC-K

XS5W-T422-GMC-K

XS5W-T422-JMC-K

XS5W-T422-KMC-K

Ethernet installation cable

Cat 5, SF/UTP, 4 × 2 × AWG 24/1 (solid core), Polyurethane (PUR)

Datasheet - PDF

▲

Título:	Tamanho:	Tipo:
PDF CATALOGO OMRON AUTOMATION EN.pdf	28 Mbytes
PDF CATALOGO OMRON PT.pdf	89 Mbytes

Avaliações: (0) ▲

Não há comentários do produto ainda.

Adicionar avaliação

Adicionar avaliação

ocultar formulário

Avaliação:
Nome:
Email:
Título:
Opinión:
Você recomendaria esse produto para comprar? Sim Não

	Adicionar avaliação

Últimas opiniões dos nossos clientes

Todas as classificações que recebemos a partir dos itens que oferecemos são reais e verificadas. Um pequeno gesto, mas muito valioso. Então, obrigado por esse minuto você gasta em deixar-nos a sua opinião e classificação de produtos, porque nos ajuda a continuar a melhorar e oferecer maior qualidade de serviço.

5 / 5 Bueno bonito y barato

— Jose Maria Rendon 2024-02-12
Avaliação do cliente:

Produto: 694965 2CDS211167R0104 AEG DG61N+ C10
5 / 5 I appreciate these items very much

— Daher Haddad 2024-01-09
Avaliação do cliente:

Produto: 121U8028 DANFOSS REFRIGERATION MLZ021T5LP9 co
5 / 5 exactly what we needed.

— John Biasucci 2023-11-30
Avaliação do cliente:

Produto: 6DR5013-0FN01-0AA3 SIEMENS SIPART PS2 smart e
2 / 5 nur in englischer Sprache bei Grundauslieferung !!

— Heiko Seliger 2023-11-09
Avaliação do cliente:

Produto: 6SL3255-0AA00-4CA1 SIEMENS SINAMICS G120 Basi...

XS6W-6PUR8SS100CM-YH 682428 XS6W6PUR8SS100CMYH OMRON Ethernet patch cable Cat.6, PUR 1 m

PRODUTOS VISUALIZADOS

XS6W-6PUR8SS100CM-YH...

SAC-5P-MS/4,0-920/FR...

SAC-8P-MS/ 3,0-PUR/FS...

Mais informação

Controlador Sysmac - Série NJ5

Ordering information

NJ series system

NJ series expansion racks

Power supply units

NJ5 series CPU units

CJ series digital I/O units

CJ series analog I/O and control units

CJ series special I/O units

CJ series communication units

CJ series ID sensor units

Expansion racks

CJ series I/O control unit (mounted on CPU rack when connecting expansion racks)

CJ series I/O interface unit (mounted on expansion rack)

I/O connecting cables

EtherCAT junction slave

Industrial switching hubs

Recommended EtherCAT and EtherNet/IP communication cables

Datasheet - PDF

Avaliações: (0) ▲

Últimas opiniões dos nossos clientes
