> SIEMENS>CONTROL AND CONTACTORS>Commanding and signaling devices>3SB2204-6BG06 SIEMENS Indicator light, 16 mm, round, plastic, white, Lampholder W2 x 4.6 d, without lamp
Previous Product Next Product
3SB2204-6BG06 SIEMENS Indicator light, 16 mm, round, plastic, white, Lampholder W2 x 4.6 d, without lamp View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

3SB2204-6BG06 SIEMENS Indicator light, 16 mm, round, plastic, white, Lampholder W2 x 4.6 d, without lamp

3SB2204-6BG06

SIEMENS

Indicator light, 16 mm, round, plastic, white, Lampholder W2 x 4.6 d, without lamp

More details


Low-voltage industrial components > Indicator light complete

CONTROL AND CONTACTORS > Commanding and signaling devices

* Brand new product in its original packaging covered by the warranties and certifications provided by SIEMENS

Total price: $12.89
Unit price: $12.89

Quantity Price
1+$12.89
2+$12.89
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

More info

▲


Technical data

Indicator light, 16 mm, round, plastic, white, Lampholder W2 x 4.6 d, without lamp
product brand nameSIRIUS
product designationIndicator lights
design of the productComplete unit round
product type designation3SB2
Enclosure
number of command points0
Actuator
design of the actuating elementindicator light
product extension optional light sourceYes
color of the actuating elementwhite
material of the actuating elementplastic
type of unlocking devicewithout
number of switching positions2
Front ring
product component front ringNo
Holder
material of the holderPlastic
Contact block/ lampholder
socket designW2 x 4.6d without lamp
number of lampholders1
number of switching elements0
General technical data
product function
● positive openingNo
● EMERGENCY STOP functionNo
product component light sourceNo
type of voltage of the operating voltageAC/DC
protection class IPIP65
vibration resistance according to IEC 60068-2-620 ... 200 Hz: 5g
reference code according to IEC 81346-2P
Substance Prohibitance (Date)07/01/2006
operating voltage rated value5 ... 60 V
Auxiliary circuit
number of NC contacts for auxiliary contacts0
number of NO contacts for auxiliary contacts0
number of CO contacts for auxiliary contacts0
Connections/ Terminals
type of electrical connectiontab terminals
tightening torque of the screws in the bracket0.4 N·m
Ambient conditions
ambient temperature
● during operation-25 ... +60 °C
● during storage-40 ... +80 °C
environmental category during operation according to IEC 607213K6
Installation/ mounting/ dimensions
fastening methodfront plate mounting
shape of the installation openinground
mounting diameter16 mm
mounting height9 mm
installation width19 mm
installation depth50 mm
Certificates/ approvals

Downloads and manuals

General Product ApprovalDeclaration of Conformity

CSA

CCC

UL

EAC

UK Declaration of Conformity

EC/EU-Declaration of Conformity

Test Certificatesother

Miscellaneous

Special Test Certificate

Confirmation

Further information
Information- and Downloadcenter (Catalogs, Brochures,…)
Industry Mall (Online ordering system)
Cax online generator
Service&Support (Manuals, Certificates, Characteristics, FAQs,...)
Image database (product images, 2D dimension drawings, 3D models, device circuit diagrams, EPLAN macros, ...)
last modified:1/26/2022
Date
5/14/2022		Subject to change without notice
© Copyright Siemens 2022


Additional data

Product
Article Number (Market Facing Number)3SB2204-6BG06
Product DescriptionIndicator light, 16 mm, round, plastic, white, Lampholder W2 x 4.6 d, without lamp
Product familyComplete units
Product Lifecycle (PLM)PM300:Active Product
Price data
Region Specific PriceGroup / Headquarter Price Group41J / 41J
Surcharge for Raw MaterialsNone
Metal FactorLA------
Delivery information
Export Control RegulationsAL : N / ECCN : N
Standard lead time ex-works2 Day/Days
Net Weight (kg)0,020 Kg
Packaging Dimension50,00 x 79,00 x 53,00
Package size unit of measureMM
Quantity Unit1 Piece
Packaging Quantity1
Additional Product Information
EAN4011209028166
UPC754554335377
Commodity Code85366190
LKZ_FDB/ CatalogIDCC-IC10
Product Group5834
Group CodeR711
Country of originCzech Republic
Compliance with the substance restrictions according to RoHS directiveSince: 01.07.2006
Product classA: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back ObligationYes
REACH Art. 33 Duty to inform according to the current list of candidates
There is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly.
Classifications
VersionClassification
eClass627-37-12-23
eClass7.127-37-12-23
eClass827-37-12-23
eClass927-37-12-23
eClass9.127-37-12-23
ETIM5EC000272
ETIM6EC000272
ETIM7EC000272
ETIM8EC000272
IDEA44766
UNSPSC1439-12-15-34
UNSPSC1539-12-15-34

ETIM data

ETIM: EC000272 - Indicator light complete

Value Unit
Construction type lens (EF006253) -
Degree of protection (NEMA) (EF011959) -
Type of lens (EF008343) -
Number of indicator lights (EF001965) 1
Colour lens (EF000207) White
Type of lamp socket (EF008229) W2 x 4.6
With light source (EF005905) false
Rated operating voltage Ue (EF002418) ['5', '60']V
Voltage type (EF000187) AC/DC
Type of electric connection (EF003961) Flat plug-in connection
Hole diameter (EF000079) 16.0mm
Width opening (EF004565) 19.0mm
Height opening (EF004778) 9.0mm
With front ring (EF006014) false
Material front ring (EF005972) -
Colour front ring (EF002429) -
Degree of protection (IP) (EF005474) IP65


Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG SIEMENS SIRIUS INDUSTRIAL CONTROLS EN.pdf 279 Mbytes
3SB2204-6BG06 3SB2204-6BG06 EN_3SB2204-6BG06.pdf 132 Kbytes 3SB2204-6BG06 3SB2204-6BG06 EN_3SB2204-6BG06.pdf
