SPC 5/ 8-STF-7,62 GY LP:8-1 SO 1774962 PHOENIX CONTACT Plug-in connector for plate circ. printed
SPC 5/ 8-STF-7,62 GY LP:8-1 SO
1774962
PHOENIX_CONTACT
50
Plug-in connector for plate circ. printed
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Connector for printed circuit board, nominal current: 41 A, voltage and sizing (III/2): 1000 V, number of poles: 8, pitch: 7.62 mm, connection type: spring clamp push-in, color: gray, surface contacts: Tin
Data commercial
| Key order | One million seven hundred seventy four thousand nine hundred sixty two |
|---|---|
| Packing unit | 50 pcs |
| Key selling | AABCCA - |
| Minimum order quantity | 50 pcs |
| EAN | Four trillion forty six billion three hundred fifty six million five hundred seven thousand six hundred fifty three |
| Unit weight (excluding packaging) | 40,000 g |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
| Country of origin | DE (Germany) |
Dimensions
| Length [ l ] | 38.5 mm |
|---|---|
| Width [ w ] | 76,18 mm |
| Height [ h ] | 19.8 mm |
| Step | 7.62 mm |
| Average | 53,34 mm |
Overview
| Family of articles | SPC 5/..-STF |
|---|---|
| Number of poles | Eight |
| Type of connection | Connection by spring loaded push-in |
| Tension and sizing (III/3) | 1000 V |
| Connection according to standard | EN-VDE |
| Nominal current IN | Forty one |
| Nominal cross section | 6 mm2 |
Data connection
| Core cross-section rigid min. | 0,2 mm2 |
|---|---|
| Section of conductor rigid max. | 10 mm2 |
| Section of flexible conductor, min. | 0,2 mm2 |
| Section of flexible conductor max. | 6 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve min. | 0.25 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve max. | 6 mm2 |
| Section of flexible conductor with toe, with plastic sleeve min. | 0.25 mm2 |
| Section of flexible conductor with toe, with plastic sleeve max. | 4 mm2 |
| Section of conductor AWG min. | Twenty four |
| Section of conductor AWG max. | Eight |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve min. | 0.25 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve max. | 1.5 mm2 |
Directions on cutting edge
| Clamp crimp recommended | 1212034 CRIMPFOX 6 |
|---|---|
| Leading without collar is insulated, according to DIN 46228-1 | Section: 0.5 mm2; Length: 10 mm ... 15 mm |
| Section: 0.75 mm2; Length: 10 mm ... 15 mm | |
| Section: 1 mm2; Length: 10 mm ... 15 mm | |
| Section: 1.5 mm2; Length: 10 mm ... 15 mm | |
| Section: 2,5 mm2; Length: 12 mm ... 15 mm | |
| Section: 4 mm2; Length: 12 mm ... 15 mm |
Standards and specifications
| Connection according to standard | EN-VDE |
|---|
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss
| eCl@ss 4.0 | 272607xx |
|---|---|
| eCl@ss 4.1 | Twenty seven million two hundred sixty thousand seven hundred one |
| eCl@ss 5.0 | Twenty seven million two hundred sixty thousand seven hundred one |
| eCl@ss 5.1 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 6.0 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand three hundred nine |
ETIM
| ETIM 3.0 | EC001121 |
|---|---|
| ETIM 4.0 | EC002638 |
| ETIM 5.0 | EC002638 |
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
UNSPSC
| UNSPSC 6.01 | Thirty million two hundred eleven thousand eight hundred ten |
|---|---|
| UNSPSC 7.0901 | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 11 | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 12.01 | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 13.2 | Thirty nine million one hundred twenty one thousand four hundred nine |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
