PTS 1,5/ 4-PH-5,0 BD:+-H 1034974 PHOENIX CONTACT Printed-circuit board connector PTS 1,5/ 4-PH-5,0 BD:+-H 10..
PTS 1,5/ 4-PH-5,0 BD:+-H
1034974
PHOENIX_CONTACT
250
Printed-circuit board connector - PTS 1,5/ 4-PH-5,0 BD:+-H - 1034974
Connector for printed circuit board, nominal section: 1.5 mm², color: green, nominal current: 10 A, nominal voltage (III/2): 400 V, contact surface: Tin, contact type: Female, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: PTS 1.5/.. -PH, pitch: 5mm, connection type: Push-in spring connection, driver/printed circuit board connection direction: 0°, plug-in system: COMBICON PST 1.3, lock: without, fixing type: without, packaging type: boxed
Connectors > Cable connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB connector, nominal current: 10 A, rated voltage (III/2): 400 V, number of positions: 4, pitch: 5 mm, connection method: Push-in spring connection, color: green, contact surface: Tin
Key Commercial Data
| Orderkey | 1034974 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626541808 |
| Custom tariff number | 85366990 |
Dimensions
| Length [ l ] | 12.8 mm |
|---|---|
| Width [ w ] | 20 mm |
| Height [ h ] | 11.7 mm |
| Pitch | 5 mm |
| Dimension a | 15 mm |
General
| Range of articles | PTS 1,5/..-PH |
|---|---|
| Number of positions | 4 |
| Connection method | Push-in spring connection |
| Nominal cross section | 1.5 mm² |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440309 |
| eCl@ss 8.0 | 27440309 |
| eCl@ss 9.0 | 27440309 |
ETIM
| ETIM 5.0 | EC002638 |
|---|---|
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
