FRONT-MC 1,5/16-STF-3,81 CN16 1797253 PHOENIX CONTACT Connector for printed circuit board, nominal current: ..
FRONT-MC 1,5/16-STF-3,81 CN16
1797253
PHOENIX_CONTACT
50
Connector for printed circuit board, nominal current: 8 A, number of poles: 16, pitch: 3,81 mm, type of connection: Connection by screw-on front, color: green, surface contacts: Tin
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Circuit board connector, nominal current: 8 A, rated operating voltage (III/2): 160 V, number of poles: 16, pitch: 3,81 mm, connection: screw Connection front, color: green, surface of contact: Tin
Commercial data
| The code for the order | One million seven hundred ninety seven thousand two hundred fifty three |
|---|---|
| Pieces/pack. | 50 PCS |
| Sales key | AAAEAA - |
| GTIN | Four trillion forty six billion three hundred fifty six million six hundred thirty nine thousand six hundred sixty eight |
| Weight per piece (package included) | 20,800 g |
| Number customs tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
Size
| Length [ l ] | 21.7 mm |
|---|---|
| Width [ w ] | 71,35 mm |
| Height [ h ] | 12.3 mm |
| Step | 3,81 mm |
| Measure | 57,15 mm |
General
| Family article | FRONT-MC 1,5/..-STF |
|---|---|
| N. of poles | Sixteen |
| Link | Screw connection front |
| Rating voltage (III/3) | 160 V |
| Attack in accordance with | EN-VDE |
| Rated current IN | Eight |
| Nominal section | 1.5 mm2 |
Data link
| Conductor cross section, rigid min. | 0.14 mm2 |
|---|---|
| Conductor cross section, rigid max. | 1.5 mm2 |
| Conductor cross section flexible min. | 0.14 mm2 |
| Conductor cross section flexible max. | 1.5 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic max. | 1.5 mm2 |
| Conductor cross section flexible with aeh with collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with aeh with collar plastic max. | 0.5 mm2 |
| Cross section conductor AWG min. | Twenty eight |
| Cross section conductor AWG max. | Sixteen |
| 2 conductors with the same diameter, rigid min. | 0.14 mm2 |
| 2 conductors with the same diameter, rigid max. | 0.5 mm2 |
| 2 conductors with the same diameter, flexible, min. | 0.14 mm2 |
| 2 conductors with the same diameter, flexible, max. | 0.75 mm2 |
| 2 conductors with the same diameter, flexible with AEH without collar plastic min. | 0.25 mm2 |
| 2 conductors with the same diameter, flexible with AEH without collar plastic max. | 0.34 mm2 |
| 2 conductors with the same diameter, flexible with TWIN-AEH with collar plastic min. | 0.5 mm2 |
| 2 conductors with the same diameter, flexible with TWIN-AEH with collar plastic max. | 0.5 mm2 |
| AWG according to UL/CUL min | Thirty |
| AWG according to UL/CUL max | Sixteen |
Regulations and requirements
| Attack in accordance with | EN-VDE |
|---|---|
| CUL |
Environmental Product Compliance
| China RoHS | Period for proper use: unlimited = EFUP-and |
|---|---|
| Any hazardous substances above the threshold values |
Rankings
eCl@ss
| eCl@ss 4.0 | 272607xx |
|---|---|
| eCl@ss 4.1 | Twenty seven million two hundred sixty thousand seven hundred one |
| eCl@ss 5.0 | Twenty seven million two hundred sixty thousand seven hundred one |
| eCl@ss 5.1 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 6.0 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand three hundred nine |
ETIM
| ETIM 4.0 | EC002643 |
|---|---|
| ETIM 5.0 | EC002638 |
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
UNSPSC
| UNSPSC 6.01 | Thirty million two hundred eleven thousand eight hundred ten |
|---|---|
| UNSPSC 7.0901 | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 11 | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 12.01 | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 13.2 | Thirty nine million one hundred twenty one thousand four hundred nine |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
