BCH-500HF-15 BK 5452364 PHOENIX CONTACT Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º..
BCH-500HF-15 BK
5452364
PHOENIX_CONTACT
100
Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º poles: 15,Pitch: 5 mm,Color: black,contact Surface: Tin,Assembly: wave Soldering
Connectors > Printed circuit board connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Commercial data
| The code for the order | Five million four hundred fifty two thousand three hundred sixty four |
|---|---|
| Pieces/pack. | 100 PCS |
| Sales key | AAYBFA - |
| The amount of minimum order | 100 PCS |
| GTIN | Four trillion forty six billion three hundred fifty six million eight hundred fifty two thousand one hundred seventy three |
| Weight per piece (package included) | 7,293 g |
| Number customs tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
Size
| Length [ l ] | 12 mm |
|---|---|
| Width | 85 mm |
| Step | 5 mm |
| Measure | 70 mm |
| Width [ w ] | 85 mm |
| Height [ h ] | 12.1 mm |
| Mounting height | 8.6 mm |
| Pin length solder | 3.5 mm |
| The size of the shanks | 1 x 1 mm |
| Length | 12 mm |
General
| Family article | BCH-HF |
|---|---|
| Group insulating material | The |
| Surge voltage strength (III/3) | 4 kV |
| Surge voltage strength (III/2) | 4 kV |
| Surge voltage strength (II/2) | 4 kV |
| Rating voltage (III/3) | 250 V |
| Rating voltage (III/2) | 320 V |
| Rating voltage (II/2) | 400 V |
| Attack in accordance with | EN-VDE |
| Rated current IN | 12 To |
| Maximum load current | 12 To |
| Insulating material | PA |
| Class behaviour according to UL 94 | V0 |
| Color | black |
| N. of poles | Fifteen |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Period of use conforms to the target without damage to the environment (EFUP): 50 years |
| The information on hazardous substances found in the declaration of the manufacturer under "Downlaods" |
Rankings
eCl@ss 4.0272607xxeCl@ss 4.1Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.0Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundredeCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundredeCl@ss 7.0Twenty seven million four hundred forty thousand four hundred twoeCl@ss 8.0Twenty seven million four hundred forty thousand four hundred twoeCl@ss 9.0Twenty seven million four hundred forty thousand four hundred two
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred oneUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred nine
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
