S8JX-G10005CD S8JX0107M S8JXG10005CD OMRON 100W / 5V / 20A With enclosure DIN Rail

15 W

5 V

3 A

91 × 40 × 90

S8JX-G01505CD

12 V

1.3 A

S8JX-G01512CD

24 V

0.65 A

S8JX-G01524CD

35 W

5 V

7 A

S8JX-G03505CD

12 V

3 A

S8JX-G03512CD

24 V

1.5 A

S8JX-G03524CD

50 W

5 V

10 A

92 × 40 × 100

S8JX-G05005CD

12 V

4.2 A

S8JX-G05012CD

24 V

2.1 A

S8JX-G05024CD

100 W

5 V

20 A

92 × 50 × 150

S8JX-G10005CD

12 V

8.5 A

S8JX-G10012CD

24 V

4.5 A

S8JX-G10024CD

150 W

12 V

13 A

92 × 60 × 178

S8JX-G15012CD

24 V

6.5 A

92 × 50 × 150

S8JX-G15024CD

300 W

12 V

27 A

92 × 110 × 164.5

S8JX-G30012CD

24 V

14 A

92 × 110 × 167

S8JX-G30024CD

600 W

24 V

27 A

92 × 150 × 160

S8JX-G60024C

48 V

13 A

S8JX-G60048C

Efficiency (Typ. at 230 VAC)

81% (24 V)

84% (24 V)

86% (24 V)

88% (24 V)

90% (24 V)

88% (24 V)

84% (24 V)

Input

Rated input voltage

100 to 240 VAC

100 to 120 VAC/200 to 240 VAC, Switchable

Allowable range

85 to 264 VAC, 80 to 370 VDC (DC is not applicable for the safety standards.)

85 to 132 VAC/170 to 264 VAC

Output

Voltage adjustment range (with V.ADJ)

−10% to 15% for 5 V to 24 V, ±10% for 48 V (with V.ADJ)

Input variation influence

0.4% max. (at 85 to 264 VAC input, 100% load)

Load variation Influence

0.8% max. at 0% to 100% load

Temperature variation influence

0.05%/°C max.

Overload protection

Yes, 105% to 160% of rated current

Overvoltage protection

Yes

Operating ambient temperature

−10 to 60°C (14 to 140°F)

Series operation

Yes, up to 2 units

Yes, up to 2 units

Parallel operation

No

Yes, up to 5 units

EMI

Conforms to EN 61204-3, EN 55011 Class A

EMS

Conforms to EN 61204-3 high severity levels

Approved standards

UL: UL 508 (Listing), UL 60950-1, cUL: CSA C22.2 No. 107.1 and No. 60950-1,
EN/VDE: EN 50178 (=VDE0160), EN 60950-1 (=VDE0805)

UL: UL 508 (Recognition), UL 60950-1,
cUR: CSA C22.2 No. 107.1 and No. 60950-1,
EN/VDE: EN 50178 (=VDE0160), EN 60950-1 (=VDE0805)

Fulfilled standards

EN 50274 for terminal parts
