866191 MURRELEKTRONIK MST single-phase control and isolation transformer P:800VA IN:110VAC OUT:230VAC
866191
MURRELEKTRONIK
10
MST single-phase control and isolation transformer P:800VA IN:110VAC OUT:230VAC
MST SINGLE-PHASE CONTROL AND ISOLATION TRANSFORMER P:800VA IN:110VAC OUT:230VAC
MST SINGLE-PHASE CONTROL AND ISOLATION TRANSFORMER
Transformers
* Brand new product in its original packaging covered by the warranties and certifications provided by MURRELEKTRONIK
Best sellers
▲More info
▲800 VA
Isolation class T 40/B
Other voltages on request.
| Standards | EN 61558-1, EN 61558-2-4, EN 62041 category 0 |
|---|---|
| Test isolation voltage | 4 kV (prim./sec.) |
| Mounting method | Key-hole mounting |
| Temperature range | -20...+40 °C (storage temperature -40...+80 °C) |
| Dimensions H×W×D | 129×150×145 mm |
| Fixing centers a×b×c | 107.5×122×7 mm |
| Drill hole Ø | 7×11 mm |
| Output voltage | 230 V AC |
|---|---|
| Output rating | 800 VA |
| Input voltage | 110 V AC |
|---|---|
| Input current | 3.8 A (110 V AC) |
| Inrush current | 83 A (110 V AC) |
| Short-circuit current | 219 A (110 V AC) |
| Frequency | 50...60 Hz |
| country of origin | CZ |
|---|---|
| customs tariff number | 85043180 |
| EAN | 4048879329002 |
| eClass | 27031202 |
| Packaging unit | 1 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRELEKTRONIK EN.pdf | 19 Mbytes |
|
| 866191 866191 EN_866191.pdf | 151 Kbytes |
|
