PMKC03-12D12-SMD MEANWELL DC-DC converter to the printed circuit board in format SMD, with 2 outputs.
PMKC03-12D12-SMD
MEANWELL
DC-DC converter to the printed circuit board in format SMD, with 2 outputs.
ADAPTERS > AC plug
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | PMKC03-12D12-SMD |
|---|---|
| Long Description | Dc/DC converter to the printed circuit board in format SMD, with 2 outputs. Plastic box. FormatSMDfor soldering on printed circuit boards. Input range9-18vdc. Outputs: -12vdc:
+12vdc:
Power:3W. Isolation input-output of 1,600 Vdc. Efficiency typical: 79%. Low noise and ripple 75mVp-p. Minimum load of 10%. The no-load operation will not damage the converter but will not meet all specifications. Working temperature: from-25up+71ºC. See the curve of drift according to the temperature in the technical data sheet. Max temperature box:+100 ° C. Dimensions (Length x Width x Height) [mm]:31,8 x 20,3 x 10,2. 3 years of warranty. Manufacturer: P-DUKE. The converters of the series PMKC03 have a wide input range 2:1 and an isolation between input and output of 1600Vcc. Are protected against overloads and short-circuits. CE certified and UL listed. |
| Country of Origin | Taiwan |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Format | For Printed Circuit |
| Subformato | SMD |
| Applications | Building automation, Industrial, Telecommunications |
| Series | PMKC03 |
| Warranty (Years) | 3,00 |
| Height (mm) | 10.2 |
| Width (mm) | 20.3 |
| Long/Background | 31.8 |
| Input range | 2:1 |
| Range DC Input | 9, 9,2, 9,9, 10, 10,5, 10,8, 12, 13,2, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18 |
| DC input Min | 9,00 |
| DC input Max | 18,00 |
| Input connector | Pin |
| Output 1 | -12 |
| Output 2 | +12 |
| Power (W) | 3,00 |
| Peak Power (W) | Three |
| Output connector | Pin |
| Isolation (V) | 1.600,00 |
| Approvals | CE, UL |
