MPP03-05D12A MEANWELL DC-DC Converter for PCB mount, Input: 4,5-9VDC, Outputs: -12 / +12VDC, Power: 3W. Isol..
MPP03-05D12A
MEANWELL
DC-DC Converter for PCB mount, Input: 4,5-9VDC, Outputs: -12 / +12VDC, Power: 3W. Isolation 5000VDC, standard DIP. 2xMOPP.
ADAPTERS > AC plug
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | MPP03-05D12A |
|---|---|
| Long Description | Dc/DC converter to the printed circuit board in format DIP, with 2 outputs andregulations medical. Plastic box, free standard. FormatDIPfor soldering on printed circuit boards. Input range4,5-9Vcc. Outputs: -12vdc:
+12vdc:
Power:3W. Isolation input-output 5000Vca. Efficiency typical 86%. Low noise and ripple of 30mVp-p. Low leakage current2µA. Working temperature: from-40up+105ºC. See the curve of drift according to the temperature in the technical data sheet. Dimensions (Length x Width x Height) [mm]:31,8 x 20,3 x 10,2. 5 years of warranty. Manufacturer: P-DUKE. The converters of the series MOP03 have a wide input range 2:1 or 4:1 and an isolation between input and output of 5000Vca. Are protected against overloads and short-circuits. Have a minimum consumption without load as well as a low leakage current. CE certified and UL listed. |
| Country of Origin | Taiwan |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Format | For Printed Circuit |
| Subformato | DIP |
| Applications | Automation of Buildings, Industrial, Instrumentation, Medical, Solar, Telecommunications |
| Series | MPP03 |
| State | New |
| Warranty (Years) | 5,00 |
| Height (mm) | 10.2 |
| Width (mm) | 20.3 |
| Long/Background | 31.8 |
| Input range | 2:1 |
| Range DC Input | 4,5, 4,6, 4,75, 5,5, 6, 6,5, 7, 8, 8,1, 8,3, 8,4, 9 |
| DC input Min | 4,50 |
| DC input Max | 9,00 |
| Input connector | Pin |
| Output 1 | -12 |
| Output 2 | +12 |
| Power (W) | 3,00 |
| Peak Power (W) | Three |
| Output connector | Pin |
| Isolation (V) | 5.000,00 |
| Approvals | CE, EN60601 3rd Edition, UL, UL60601 3rd Edition |
