LVMP30A240 LOVATO ALTERN. RELAY FOR 3-4 PUMPS, 100-240VAC
LVMP30A240
LOVATO ELECTRIC
ALTERN. RELAY FOR 3-4 PUMPS, 100-240VAC
Start-up priority change relay for 3 or 4 motors, modular version. Auxiliary supply voltage 100…240VAC
RELE' SCAMBIO 3-4 POMPE, ALIM.100-240VAC
PLC's > Logic module
Level control relays - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Related products
▲Best sellers
▲More info
▲LVMP30A240
Start-up priority change relay for 3 or 4 motors, modular version. Auxiliary supply voltage 100…240VAC
Technical specifications
- Type of product:
- Start-up priority change relays
- Functions:
- Priority change for 3-4 motors
- Number of relay outputs:
- 4
- Rated supply voltage:
- 100…240VAC
- Type of installation:
- Modular DIN rail mounting
| Order code | LVMP30A240 |
|---|---|
| Weight [g] | 242 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 080X100X066 |
| Volume [cm³] | 528 |
| Bar code [EAN13] | 8013975322345 |
| HS Code | 85364900 |
152.13 £
| Feature Name | Feature Value |
|---|---|
| Supply voltage AC 60 Hz (EF007533) | 100 V |
| Supply voltage AC 50 Hz (EF007532) | 100 V |
| Number of HW-interfaces wireless (EF006933) | 0 |
| Number of interfaces PROFINET (EF006932) | 0 |
| Number of HW-interfaces other (EF003027) | 0 |
| Number of HW-interfaces parallel (EF003026) | 0 |
| Number of HW-interfaces USB (EF003025) | 0 |
| Number of HW-interfaces serial TTY (EF003024) | 0 |
| Number of HW-interfaces RS-485 (EF003023) | 0 |
| Number of HW-interfaces RS-422 (EF003022) | 0 |
| Number of HW-interfaces RS-232 (EF003021) | 0 |
| Number of HW-interfaces industrial Ethernet (EF003020) | 0 |
| Number of analogue outputs (EF001995) | 0 |
| Number of analogue inputs (EF001994) | 0 |
| Number of digital outputs (EF001993) | 4 |
| Number of digital inputs (EF001992) | 6 |
| Depth (EF000049) | 59.6 mm |
| Height (EF000040) | 90 mm |
| Width (EF000008) | 72 mm |
| Radio standard UMTS (EF008525) | No |
| Radio standard GSM (EF008524) | No |
| Radio standard GPRS (EF008523) | No |
| Supporting protocol for SafetyBUS p (EF007527) | No |
| Supporting protocol for PROFIsafe (EF007526) | No |
| Supporting protocol for PROFINET IO (EF007525) | No |
| Supporting protocol for PROFINET CBA (EF007524) | No |
| Supporting protocol for Foundation Fieldbus (EF007522) | No |
| Supporting protocol for EtherNet/IP (EF007521) | No |
| Supporting protocol for DeviceNet Safety (EF007520) | No |
| Supporting protocol for AS-Interface Safety at Work (EF007519) | No |
| IO link master (EF007298) | No |
| Basic device (EF007279) | Yes |
| Radio standard WLAN 802.11 (EF007179) | No |
| Radio standard Bluetooth (EF007178) | No |
| Expansion device (EF007163) | No |
| Wall mounting/direct mounting (EF007020) | No |
| Rack-assembly possible (EF007018) | No |
| Front built-in possible (EF007016) | No |
| Supporting protocol for INTERBUS-Safety (EF006662) | No |
| Supporting protocol for SERCOS (EF006657) | No |
| Suitable for rail mounting (EF003972) | Yes |
| With relay output (EF003198) | Yes |
| Redundancy (EF003156) | No |
| Supporting protocol for other bus systems (EF003062) | No |
| Supporting protocol for SUCONET (EF003060) | No |
| Supporting protocol for DeviceNet (EF003059) | No |
| Supporting protocol for Data-Highway (EF003058) | No |
| Supporting protocol for Modbus (EF003057) | No |
| Supporting protocol for KNX (EF003055) | No |
| Supporting protocol for INTERBUS (EF003054) | No |
| Supporting protocol for CAN (EF003053) | No |
| Supporting protocol for PROFIBUS (EF003052) | No |
| Supporting protocol for ASI (EF003051) | No |
| Supporting protocol for TCP/IP (EF003050) | No |
| With optical interface (EF003028) | No |
| Supporting protocol for LON (EF003017) | No |
| Suitable for safety functions (EF001597) | No |
| With display (EF000458) | Yes |
| With time switch clock (EF000256) | Yes |
| Expandable (EF000119) | Yes |
| Degree of protection (IP) (EF005474) | IP20 |
| Voltage type (supply voltage) (EF002991) | AC |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
