7GN4053O GN4053O LOVATO Switch "1-0-2" 3-pole GN53 40 TO Model Or 65x65
7GN4053O
GN4053O
LOVATO ELECTRIC
Switch "1-0-2" 3-pole GN53 40 TO Model Or 65x65
Rotary cam switch 7GN series, changeover switch 3 poles 40A, for rear mounting with black handle, front plate 65X65mm
Low-voltage industrial components > Selector switch, complete
Rotary cam switches - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲7GN4053O
Rotary cam switch 7GN series, changeover switch 3 poles 40A, for rear mounting with black handle, front plate 65X65mm
Technical specifications
- Type of product:
- Changeover switches
- Switching diagram:
- 53 - Changeover switch 3 poles - 2 speed motor starting with separate windings
- IEC Conventional free air thermal current Ith [A]:
- 40
- Mounting form:
- O - Rear mounting with black handle
- Series:
- 7GN - round-shaped contact block
| Order code | 7GN4053O |
|---|---|
| Weight [g] | 306 |
| Qty. per package | 0 |
| Multiple qty. of packs per order | 0 |
| Package dimensions [mm] | 068X068X132 |
| Volume [cm³] | 610.368 |
| Bar code [EAN13] | 3850144041998 |
| HS Code | 85365080 |
| Feature Name | Feature Value |
|---|---|
| Type of control element (EF006976) | Short thumb-grip |
| Material front ring (EF005972) | Plastic |
| Degree of protection (IP) (EF005474) | IP40 |
| Type of electric connection (EF003961) | Screw connection |
| With front ring (EF006014) | No |
| With light source (EF005905) | No |
| Spring-return (EF001407) | No |
| Suitable for lighting (EF001142) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 3 |
| Number of contacts as normally closed contact (EF008255) | 0 |
| Number of switch positions (EF000231) | 3 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
