7GN32124O GN32124O LOVATO Switch bipolar with "0" position 3 Positions GN124 32 TO Model Or 65x65
7GN32124O
GN32124O
LOVATO ELECTRIC
Switch bipolar with "0" position 3 Positions GN124 32 TO Model Or 65x65
Bipolar switch with position "0" 3 Positions GN124 32 A Model O 65x65
Rotary cam switch 7GN series, multi-step 0-1-2-3, 2 poles 32A, for rear mounting with black handle, front plate 65X65mm
ROTARY CAM SWITCH 7GN SERIES, MULTI-STEP 0-1-2-3 2 POLES 32A, FOR REAR MOUNTING WITH BLACK HANDLE, FRONT PLATE 65X65MM
Low-voltage industrial components > Off-load switch
Rotary cam switches - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲7GN32124O
Rotary cam switch 7GN series, multi-step 0-1-2-3, 2 poles 32A, for rear mounting with black handle, front plate 65X65mm
Technical specifications
- Type of product:
- Multi-step
- Switching diagram:
- 124 - Multi-step 0-1-2-3 2 poles
- IEC Conventional free air thermal current Ith [A]:
- 32
- Mounting form:
- O - Rear mounting with black handle
- Series:
- 7GN - round-shaped contact block
| Order code | 7GN32124O |
|---|---|
| Weight [g] | 328 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | |
| Volume [cm³] | 0 |
| Bar code [EAN13] | 3850144150606 |
| HS Code | 85365080 |
| Feature Name | Feature Value |
|---|---|
| Type of control element (EF006976) | Short thumb-grip |
| Type of electrical connection of main circuit (EF006819) | Screw connection |
| Degree of protection (IP), front side (EF003118) | IP40 |
| Housing material (EF001596) | Plastic |
| Model (EF000010) | Other |
| Complete device in housing (EF007317) | Yes |
| Suitable for intermediate mounting (EF007264) | No |
| Suitable for distribution board installation (EF007262) | Yes |
| Suitable for front mounting (EF007246) | No |
| Suitable for floor mounting (EF007243) | No |
| With retraction in 0-position (EF002428) | No |
| With zero (off) position (EF001416) | Yes |
| Number of poles (EF001391) | 6 |
| Rated permanent current Iu (EF001389) | 32 A |
| Rated operation power at AC-3, 400 V (EF001364) | 11 kW |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
