GN20011O LOVATO 3PH REVERS. SW. 200A REAR MOUNT. 132X132
GN20011O
LOVATO ELECTRIC
3PH REVERS. SW. 200A REAR MOUNT. 132X132
Rotary cam switch GN series, 3-phase motor reversing switch 200A, for rear mounting with black handle, front plate 132X132mm
ROTARY CAM SWITCH GN SERIES, 3-PHASE MOTOR REVERSING SWITCH 200A, FOR REAR MOUNTING WITH BLACK HANDLE, FRONT PLATE 132X132MM
Low-voltage industrial components > Off-load switch
Rotary cam switches - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲GN20011O
Rotary cam switch GN series, 3-phase motor reversing switch 200A, for rear mounting with black handle, front plate 132X132mm
Technical specifications
- Type of product:
- Motor starting switches
- Switching diagram:
- 11 - 3-phase motor reversing switch
- IEC Conventional free air thermal current Ith [A]:
- 200
- Mounting form:
- O - Rear mounting with black handle
- Series:
- GN - power applications
| Order code | GN20011O |
|---|---|
| Weight [g] | 2443 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 250X195X155 |
| Volume [cm³] | 0 |
| Bar code [EAN13] | 3850144161160 |
| HS Code | 85365080 |
| Feature Name | Feature Value |
|---|---|
| Type of control element (EF006976) | Short thumb-grip |
| Type of electrical connection of main circuit (EF006819) | Screw connection |
| Housing material (EF001596) | Plastic |
| Model (EF000010) | Reverser |
| Complete device in housing (EF007317) | Yes |
| Suitable for intermediate mounting (EF007264) | No |
| Suitable for distribution board installation (EF007262) | Yes |
| Suitable for front mounting (EF007246) | No |
| Suitable for floor mounting (EF007243) | No |
| With retraction in 0-position (EF002428) | No |
| With zero (off) position (EF001416) | Yes |
| Number of poles (EF001391) | 6 |
| Rated permanent current Iu (EF001389) | 200 A |
| Rated operation power at AC-3, 400 V (EF001364) | 47 kW |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
