7GN2566O48 GN2566O48 LOVATO VOLTM. SW. VLN/VLL 25A MODULAR DIN RAIL
7GN2566O48
GN2566O48
LOVATO ELECTRIC
VOLTM. SW. VLN/VLL 25A MODULAR DIN RAIL
Rotary cam switch 7GN series, voltmeter switch for phase-neutral and phase-phase voltages 25A, modular service cover for 35mm DIN reail mounting with black handle, front plate 45X54mm
Low-voltage industrial components > Selector switch, complete
Rotary cam switches - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲7GN2566O48
Rotary cam switch 7GN series, voltmeter switch for phase-neutral and phase-phase voltages 25A, modular service cover for 35mm DIN reail mounting with black handle, front plate 45X54mm
Technical specifications
- Type of product:
- Voltmeters and ammeters
- Switching diagram:
- 66 - Voltmeter switch for phase-neutral and phase-phase voltages
- IEC Conventional free air thermal current Ith [A]:
- 25
- Mounting form:
- O48 - Modular service cover for 35mm din rail mounting with black handle
- Series:
- 7GN - round-shaped contact block
| Order code | 7GN2566O48 |
|---|---|
| Weight [g] | 153 |
| Qty. per package | 0 |
| Multiple qty. of packs per order | 0 |
| Package dimensions [mm] | 067X067X130 |
| Volume [cm³] | 0 |
| Bar code [EAN13] | 3850144044326 |
| HS Code | 85365080 |
| Feature Name | Feature Value |
|---|---|
| Type of control element (EF006976) | Short thumb-grip |
| Material front ring (EF005972) | Plastic |
| Degree of protection (IP) (EF005474) | IP40 |
| Type of electric connection (EF003961) | Screw connection |
| With front ring (EF006014) | No |
| With light source (EF005905) | No |
| Spring-return (EF001407) | No |
| Suitable for lighting (EF001142) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 3 |
| Number of contacts as normally closed contact (EF008255) | 0 |
| Height opening (EF004778) | 45 mm |
| Width opening (EF004565) | 54 mm |
| Number of switch positions (EF000231) | 7 |
| Hole diameter (EF000079) | 45 mm |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
