2170453 ETHERLINE ROBUST Cat.7 FLEX LAPP ETHERLINE ROBUST Cat.7 FLEX

Benefits

• Outstanding weather, ozone and UV resistance together with the wide temperature range enable versatile use for indoor and outdoor applications
• Resistant to contact with plant, animal or synthetic-based organic substances, oils, greases, waxes and the related emulsions
• Good resistance to ammonia compounds and bio-gases
• Good resistance to cold and hot water as well as water-soluble cleaning and cooling agents
• Well-suited to steam cleaning

Application range

• For flexible applications
  (7-wire stranded conductor)
• Machine tool building, medical technology, laundries, car washing equipment, chemical industry, composting plants, sewage works
• Food and beverage industry, especially for production and processing equipment of milk and meat products
• for industrial secondary and tertiary cabling according to EN 50173-3
  ISO/IEC 24702

Product features

• UV-resistant according to ISO 4892-2
• Halogen-free materials
• Good chemical resistance to ester-based hydraulic fluids
• Ozone-resistant according to EN 50396
• Low smoke density according to IEC 61034-2

Product Make-up

• 7-wire bare stranded copper conductor
• Core insulation: Based on Polyolefin
• Screening: wrapped with braided tinned-copper wires
• Outer sheath made of special TPE
• Colour: black

Classification ETIM 5

• ETIM 5.0 Class-ID: EC000830
• ETIM 5.0 Class-Description: Data cable

Classification ETIM 6

• ETIM 6.0 Class-ID: EC000830
• ETIM 6.0 Class-Description: Data cable

Minimum bending radius

• Fixed installation: 8 x outer diameter
• Flexing: 10 x outer diameter

Characteristic impedance

• nom. 100 Ω acc. to IEC 61156-6

Temperature range

• Fixed installation: -50°C to +80°C
• Flexing: -40°C to +80°C
