SW-GALILEO-S 171500 EATON ELECTRIC Visualization Software, GALILEO for all XV/XP switchgear, single-user lic.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

SW-GALILEO-S 171500 EATON ELECTRIC Visualization Software, GALILEO for all XV/XP switchgear, single-user lic..

SW-GALILEO-S

171500

EATON-MOELLER

Visualization Software, GALILEO for all XV/XP switchgear, single-user license, update from GALILEO V 8.1.2

SW-GALILEO-S

More details


PLC's > Visualization software

HMI Touch Terminals

* Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER

Total price: $705.26
Unit price: $705.26

Quantity Price
1+$705.26
2+$660.91
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Often bought together

▲

More info

▲


Visualization Software, GALILEO for all XV/XP switchgear, single-user license, update from GALILEO V 8.1.2
GALILEO, a visualization program that takes little time to master, is an intuitive and powerful engineering environment., that meets virtually every requirements involved in on-site machine operation. The visualization software is designed to meet the needs of any industry while providing comprehensive configuration options for all XV devices and PC runtime solutions. As part of this approach, it puts its full functionality at the disposal of design engineers at all times, avoiding nested variable and screen limitations. This version is a single-user license, i.e. , the software can be installed on one single computer only. supports update from Galileo version 8.1.2

General specifications
Product name
Eaton GALILEO Software
Part no.
SW-GALILEO-S
EAN
7640130098022
Product Length/Depth
230 millimetre
Product height
2 millimetre
Product width
162 millimetre
Product weight
0.016 kilogram
Certifications
UL/CSA certification not required
Product Tradename
GALILEO
Product Type
Software
Product Sub Type
None
General information
Features
Loadable for operating system for configuration software, Windows XP
Loadable for operating system for configuration software, Windows 2000
Loadable for operating system for configuration software, Windows Vista
Loadable for operating system for configuration software, Windows 7
Loadable for operating system for configuration software, Windows 9x
Loadable for operating system for configuration software, Windows NT
Loadable for operating system for configuration software, Windows 8
Alarm-management
Online projecting possible
Language switch possible
User groups (password protection) possible
Fitted with:
OPC-interface, server
Other script language
OPC-interface, client
Programming interfaces
Operating system
Runtime operation system, Windows Vista
Runtime operating system, Windows 2000
Runtime operating system, Windows XP
Software
Supports update for GALILEO version 8.1.2 or higher
For creating projects to operate and visualize machines, plants and buildings
Microsoft Windows™-based, intelligent and interactive visualization tool
Comprehensive help and documentation
GALILEO
Single-user license
Suitable for
Operating system Windows 7
Web-clients
Operating system Windows 8
Operating system Windows 10

Technical data ETIM 9.0

Programmable logic controllers PLC (EG000024) / Visualization software (EC001416)
Electric engineering, automation, process control engineering / Control, Process Control System (PCS) / Control software / Visualization software (ecl@ss13-27-24-25-02 [AKE561020])
With OPC-interface, server
Yes
With OPC-interface, client
Yes
With programming interfaces
Yes
Runtime operating system, Windows XP
No
Runtime operating system, Windows 2000
No
Runtime operating system, Linux
No
Runtime operation system, Windows Vista
No
Suitable for operating system Windows 7
Yes
Suitable for operating system Windows 8
Yes
Suitable for operating system Windows 10
Yes
Runtime operating system, other
No
Loadable for operating system for configuration software, Windows 9x
Yes
Loadable for operating system for configuration software, Windows NT
Yes
Loadable for operating system for configuration software, Windows 2000
Yes
Loadable for operating system for configuration software, Windows XP
Yes
Loadable for operating system for configuration software, Linux
No
Loadable for operating system for configuration software, Windows ME
No
Loadable for operating system for configuration software, Windows Vista
Yes
Loadable for operating system for configuration software, Windows 2003 Server
No
Loadable for operating system for configuration software, Windows 7
Yes
Loadable for operating system for configuration software, Windows 8
Yes
Min. required main memory for runtime system
256 MB
Min. required main memory for configuration software
128 MB
Industry- and technological expansions
Integrated
Multi-user capable, runtime
No
Max. number of servers
1
Max. number of clients
10
Suitable for web-clients
Yes
SCADA functionality
No
Alarm-management
Yes
Trend representation
Yes
Max. number of multi-users configuration
1
Online projecting possible
Yes
Integrable in the engineering software o.t autom.system
No
Number of online/runtime languages
100
Language switch possible
Yes
Number of configuration-/runtime languages
100
Number of configuration-/desktop languages
2
With script language Visual Basic
No
With other script language
Yes
Library with object elements
Integrated
User groups (password protection) possible
Yes
Message system
Integrated
User archive/recipes management
Integrated
Reporting system/protocol system
Integrated
Function process diagnostics
Integrated
SQL-database
Optional
Min. required processor speed for runtime system
0.2 GHz
Min. required processor speed for configuration software
1 GHz

Datasheet - PDF

▲
Title: Size: Type:
SW-GALILEO-S SW-GALILEO-S 171500 EN_171500.pdf 110 Kbytes SW-GALILEO-S SW-GALILEO-S 171500 EN_171500.pdf
