FRBDM-D20/2/003-G/A 168211 Y7-168211 EATON ELECTRIC RCD/MCB comb. switch, 20A, 30mA, miniature circuit-break..
FRBDM-D20/2/003-G/A
168211
Y7-168211
EATON-MOELLER
RCD/MCB comb. switch, 20A, 30mA, miniature circuit-breaker type D trip characteristic, 2p, residual current circuit-breaker trip characteristic: A
FRBDM-D20/2/003-G/A
Eaton Moeller series xEffect - FRBdM RCBO - residual-current circuit breaker with overcurrent protection. RCD/MCB, 20A, 30mA, MCB trip type D, 2p, RCCB trip type: A
High-quality residual current device/miniature circuit breaker combination, line voltage-dependent, contact position indicator red - green, terminal rear plug protection, tri-stable slide catch - enables removal from existing busbar system, comprehensive range of accessories suitable for subsequent installation, wide range of rated fault currents, rated operational currents up to 40 A, tripping characteristics B, C, D, rated breaking capacity 10 kA, suitable for outdoor use (on-site power and outdoor distribution board) up to -25 °C
Circuit breakers and fuses > Earth leakage circuit breaker
Modular Switchgear – Industrial
Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER
Related products
▲Best sellers
▲More info
▲General specifications
RoHS conform
Delivery Program
Technical Data - Electrical
Technical Data
| Feature Name | Feature Value |
|---|---|
| Number of poles (total) (EF008618) | 2 |
| Number of protected poles (EF005548) | 2 |
| Rated voltage (EF000228) | 240 V |
| Rated insulation voltage Ui (EF001366) | 250 V |
| Rated impulse withstand voltage Uimp (EF011980) | 4 kV |
| Rated current (EF000227) | 20 A |
| Rated fault current (EF002358) | 0.03 A |
| Leakage current type (EF002560) | A |
| Current limiting class (EF002568) | 3 |
| Power loss (EF005387) | 5.4 W |
| Rated short-circuit breaking capacity according to EN 61009 (EF012628) | 10 kA |
| Rated short-circuit breaking capacity according to IEC 60947-2 (EF006065) | 0 kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 (EF011981) | 10 kA |
| Disconnection characteristic (EF012587) | Short-time delayed |
| Surge current capacity (EF002564) | 3 kA |
| Voltage type (EF000187) | AC |
| Frequency (EF005455) | 50 Hz |
| Release characteristic (EF000889) | D |
| Concurrently switching neutral conductor (EF005997) | No |
| With interlocking device (EF007385) | No |
| Over voltage category (EF002569) | 3 |
| Pollution degree (EF002570) | 2 |
| Ambient temperature during operating (EF007515) | -25 °C |
| Width in number of modular spacings (EF002950) | 2 |
| Built-in depth (EF000218) | 70 mm |
| Anti-nuisance tripping version (EF009497) | Yes |
| Degree of protection (IP) (EF005474) | IP20 |
| Connectable conductor cross section solid-core (EF007337) | 1 mm² |
| Connectable conductor cross section multi-wired (EF007343) | 1 mm² |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF EATON XEFFECT SWITCHGEAR RANGE EN.pdf | 8 Mbytes |
|
| PDF CATALOGUE EATON EN .pdf | 38 Mbytes |
|
| FRBDM-D20/2/003-G/A Y7-168211 168211 DE_168272.pdf | 351 Kbytes |
|
