FRBDM-D10/1N/003-G/A 168274 EATON ELECTRIC RCD/MCB comb. switch, 10A, 30mA, miniature circuit-br. type D tri.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

FRBDM-D10/1N/003-G/A 168274 EATON ELECTRIC RCD/MCB comb. switch, 10A, 30mA, miniature circuit-br. type D tri..

FRBDM-D10/1N/003-G/A

168274

Y7-168274

EATON-MOELLER

RCD/MCB comb. switch, 10A, 30mA, miniature circuit-br. type D trip characteristic, 1-phase+N, residual current circuit-br. trip characteristic: A

FRBDM-D10/1N/003-G/A

Eaton Moeller series xEffect - FRBdM RCBO - residual-current circuit breaker with overcurrent protection. RCD/MCB, 10A, 30mA, MCB trip type D, 1-phase+N, RCCB trip type: A

More details


Circuit breakers and fuses > Earth leakage circuit breaker

Modular Switchgear – Industrial

* Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER

Total price: $212.33
Unit price: $212.33

Quantity Price
1+$212.33
2+$209.50
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


General specifications

Product Name
Eaton Moeller series xEffect - FRBdM RCBO - residual-current circuit breaker with overcurrent protection
Catalog Number
168274
Model Code
FRBDM-D10/1N/003-G/A
EAN
4015081648535
Product Length/Depth
86 mm
Product Height
75 mm
Product Width
37 mm
Product Weight
0.25 kg
Compliances
CE Marked
RoHS conform
Certifications
CE

Delivery Program

Basic function
Combined RCD/MCB devices
Number of poles
Single-pole + N
Tripping
Short time-delayed
Tripping characteristic
D
Application
Switchgear for industrial and advanced commercial applications
Rated switching capacity (IEC/EN 61009)
10 kA
Type
RCBO
Product range
FRBdM
Impulse withstand current
Surge-proof, 3 kA

Technical Data - Electrical

Rated operational voltage (Ue) - max
240 V
Sensitivity type
Pulse-current sensitive
Rated current
10 A

Technical Data

Number of poles (total)
2
Number of poles (protected)
1
Rated impulse withstand voltage (Uimp)
4 kV
Leakage current type
A
Current limiting class
3
Rated short-circuit breaking capacity (EN 61009)
10 kA
Rated short-circuit breaking capacity (EN 61009-1)
10 kA
Rated short-circuit breaking capacity (EN 60947-2)
0 kA
Disconnection characteristic
Short-time delayed
Surge current capacity
3 kA
Voltage type
AC
Release characteristic
D
Overvoltage category
III
Pollution degree
2

Datasheet - PDF

▲
Title: Size: Type:
PDF EATON XEFFECT SWITCHGEAR RANGE EN.pdf 8 Mbytes
PDF CATALOGUE EATON EN.pdf 51 Mbytes
FRBDM-D10/1N/003-G/A 168274 DE_168272.pdf 351 Kbytes FRBDM-D10/1N/003-G/A 168274 DE_168272.pdf
