F204 A-25/0,03 110V 2CSF204199R1250 ABB Residual Current Circuit Breaker 4P 25A 30mA
F204 A-25/0,03 110V
2CSF204199R1250
ABB
Residual Current Circuit Breaker 4P 25A 30mA
Tertiary / Industrial > F200A
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲Ordering
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85363030 |
Popular Downloads
| Data Sheet, Technical Information: | 9AKK107046A0424 |
| Instructions and Manuals: | Manual sheet inside the box |
Dimensions
| Product Net Width: | 0.070 m |
| Product Net Height: | 0.085 m |
| Product Net Depth / Length: | 0.069 m |
| Product Net Weight: | 0.350 kg |
Technical
| Standards: | IEC 61008 UL 1053 |
| Operating Characteristic: | Instantaneous |
| Type of Residual Current: | A type |
| Rated Residual Current: | 30 mA |
| Rated Current (In): | 25 A |
| Number of Poles: | 4 |
| Position of Neutral Terminals: | Right |
| Power Loss: | at Rated Operating Conditions per Pole 1.3 W |
Environmental
| Ambient Air Temperature: | Operation -25 ... +55 °C Storage -40 ... +70 °C |
| RoHS Status: | Following EU Directive 2011/65/EU |
Technical UL/CSA
| Maximum Operating Voltage UL/CSA: | 480Y / 277 V AC |
Certificates and Declarations (Document Number)
| Declaration of Conformity - CE: | 9AKK106713A5602 |
| Environmental Information: | Refer to RoHS |
| Instructions and Manuals: | Manual sheet inside the box |
| RoHS Information: | 2CSC423001K2702 |
Container Information
| Package Level 1 Units: | 1 piece |
| Package Level 1 Width: | 0.078 m |
| Package Level 1 Height: | 0.103 m |
| Package Level 1 Depth / Length: | 0.078 m |
| Package Level 1 Gross Weight: | 0.410 kg |
| Package Level 1 EAN: | 8012542776734 |
Classifications
| Object Classification Code: | Q |
| ETIM 4: | EC000003 - Residual current circuit breaker (RCCB) |
| ETIM 5: | EC000003 - Residual current circuit breaker (RCCB) |
| ETIM 6: | EC000003 - Residual current circuit breaker (RCCB) |
| ETIM 7: | EC000003 - Residual current circuit breaker (RCCB) |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF MINIATURE CIRCUIT BREAKERS EN .pdf | 37 Mbytes |
|
| F204 A-25/0,03 110V 2CSF204199R1250 2CSF204199R1250_F204_A-25_0_03_110V.pdf | 210 Kbytes |
|
