2CDS254280R0324 ABB Int.aut. S204C-C32 4 32A C 6 kA
2CDS254280R0324
ABB
Int.aut. S204C-C32 4 32A C 6 kA
S204C-C32 Miniature Circuit Breaker C-char.,6kA, 32A, 4P 2M
Circuit breakers and fuses > Miniature circuit breaker (MCB)
Tertiary / Industrial
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲b'
General Information
S204C-C32
2CDS254280R0324
4053546043709
Miniature Circuit Breakers MCBs - S200C - 4P - C - 32 ampere
S204C-C32 Miniature Circuit Breaker C-char.,6kA, 32A, 4P 2M
Technical
IEC/EN 60898-1
4
4
C
32 A
415 V AC
15.2 W
50 Hz
60 Hz
6 kA
6 kA
10000 cycle
20000 cycle
Busbar 10 mm²
Flexible 1 ... 10 mm²
Rigid 1 ... 16 mm²
Arbitrary
Environmental
Operation -25 ... +55 °C
Storage -40 ... +70 °C
Following EU Directive 2011/65/EU
Dimensions
36 mm
70 mm
86 mm
0.32 kg
Container Information
carton 6 piece
217 mm
80 mm
92 mm
1.97 kg
4053546045307
Ordering
6 piece
85362010
Certificates and Declarations (Document Number)
Popular Downloads
Classifications
EC000042 - Miniature circuit breaker (MCB)
EC000042 - Miniature circuit breaker (MCB)
7.0 27141901
39121614
| Feature Name | Feature Value |
|---|---|
| Built-in depth (EF000218) | 70 mm |
| Release characteristic (EF000889) | C |
| Number of poles (total) (EF008618) | 4 |
| Number of protected poles (EF005548) | 4 |
| Rated current (EF000227) | 32 A |
| Rated voltage (EF000228) | 415 V |
| Rated insulation voltage Ui (EF001366) | 500 V |
| Rated impulse withstand voltage Uimp (EF011980) | 4 kV |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V (EF009556) | 6 kA |
| Voltage type (EF000187) | AC |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V (EF009555) | 6 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V (EF009557) | 6 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V (EF009558) | 6 kA |
| Frequency (EF000416) | 50 Hz |
| Current limiting class (EF002568) | 3 |
| Flush-mounted installation (EF007517) | No |
| Concurrently switching neutral conductor (EF005997) | No |
| Over voltage category (EF002569) | 3 |
| Pollution degree (EF002570) | 2 |
| Additional equipment possible (EF008148) | Yes |
| Width in number of modular spacings (EF002950) | 2 |
| Degree of protection (IP) (EF005474) | IP20 |
| Ambient temperature during operating (EF007515) | -25 °C |
| Connectable conductor cross section multi-wired (EF007343) | 1 mm² |
| Connectable conductor cross section solid-core (EF007337) | 1 mm² |
| Explosion-proof (EF004663) | No |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF MINIATURE CIRCUIT BREAKERS EN .pdf | 37 Mbytes |
|
