MKKDS 5/ 8-9,5 BEIGE NZKHB3521
1869376
PHOENIX_CONTACT
1
Do PWB bloco terminal
PCB terminal block, number of positions per row: 8, product range: MKKDS 5, pitch: 9.52 mm, screw head form: L Slotted, Pin layout: Linear pinning, Solder pin [P]: 5.2 mm, type of packaging: packed in cardboard. The article can be aligned to create different nos. of positions!
Conectores PCB
* Produto novo em sua embalagem original com todas as garantias e certificações de PHOENIX_CONTACT
Obrigado pelo seu interesse nos nossos artigos, esperamos que o prazo indicado seja conveniente para si.
Durante a preparação do pedido pode seleccionar o tipo de envío que melhor se adapte ás suas necessidades: Aéreo Express 24Hrs, Terrestre Standard 48/72Hrs, etc.
Type | PC terminal block can be aligned |
Product type | Printed circuit board terminal |
Product family | MKKDS 5 |
Number of positions | 8 |
Pitch | 9.52 mm |
Pin layout | Linear pinning |
Maximum load current | 41 A |
Rated voltage (II/2) | 1000 V |
Rated voltage (III/2) | 630 V |
Rated surge voltage (II/2) | 6 kV |
Rated surge voltage (III/2) | 6 kV |
Rated surge voltage (III/3) | 6 kV |
Mounting type | Wave soldering |
Pin layout | Linear pinning |
Drive form screw head | Slotted (L) |
Connection method | Screw connection with tension sleeve |
Drive form screw head | Slotted (L) |
Color | beige |
Flammability rating according to UL 94 | V0 |
Insulating material group | I |
Insulating material | PA |
Contact surface | Tin Sn |
Width | 80.92 mm |
Height | 44.1 mm |
Installed height | 38.9 mm |
Length of the solder pin | 5.2 mm |
Length | 28 mm |
Length of the solder pin | 5.2 mm |
Hole diameter | 1.3 mm |
Pitch | 9.52 mm |
Type of packaging | packed in cardboard |
