Features
Version as main switch
Version as emergency stop installation
Version as maintenance-/service switch
10.10 Temperature rise
The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
10.11 Short-circuit rating
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.12 Electromagnetic compatibility
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.13 Mechanical function
The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
10.2.2 Corrosion resistance
Meets the product standard's requirements.
10.2.3.1 Verification of thermal stability of enclosures
Meets the product standard's requirements.
10.2.3.2 Verification of resistance of insulating materials to normal heat
Meets the product standard's requirements.
10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects
Meets the product standard's requirements.
10.2.4 Resistance to ultra-violet (UV) radiation
UV resistance only in connection with protective shield.
10.2.5 Lifting
Does not apply, since the entire switchgear needs to be evaluated.
10.2.6 Mechanical impact
Does not apply, since the entire switchgear needs to be evaluated.
10.2.7 Inscriptions
Meets the product standard's requirements.
10.3 Degree of protection of assemblies
Does not apply, since the entire switchgear needs to be evaluated.
10.4 Clearances and creepage distances
Meets the product standard's requirements.
10.5 Protection against electric shock
Does not apply, since the entire switchgear needs to be evaluated.
10.6 Incorporation of switching devices and components
Does not apply, since the entire switchgear needs to be evaluated.
10.7 Internal electrical circuits and connections
Is the panel builder's responsibility.
10.8 Connections for external conductors
Is the panel builder's responsibility.
10.9.2 Power-frequency electric strength
Is the panel builder's responsibility.
10.9.3 Impulse withstand voltage
Is the panel builder's responsibility.
10.9.4 Testing of enclosures made of insulating material
Is the panel builder's responsibility.
Rated impulse withstand voltage (Uimp)
Rated permanent current at AC-21, 400 V
Rated permanent current at AC-23, 400 V
Rated uninterrupted current (Iu)
Accessories
Auxiliary contact or neutral conductor fitted by user.
Device construction
Built-in device fixed built-in technique
Rated short-time withstand current (Icw)
Electrical connection type of main circuit
Ambient operating temperature - max
Ambient operating temperature - min
Number of auxiliary contacts (change-over contacts)
Number of auxiliary contacts (normally closed contacts)
Rated conditional short-circuit current (Iq)
Control circuit reliability
1 failure per 100,000 switching operations statistically determined, at 24 V DC, 10 mA)
Degree of protection (front side)
Suitable for
Intermediate mounting
Ground mounting
Functions
Optional Stop Function
Interlockable
Screw size
4 mm AF, Hexagon socket-head spanner, Terminal screw
Switching capacity (auxiliary contacts, general use)
Switching capacity (auxiliary contacts, pilot duty)
Switching capacity (main contacts, general use)
100 A, Rated uninterrupted current max. (UL/CSA)
Safety parameter (EN ISO 13849-1)
B10d values as per EN ISO 13849-1, table C.1
Number of auxiliary contacts (normally open contacts)
Rated operating voltage (Ue) - max
Rated operating voltage (Ue) - min
Rated operational voltage (Ue) at AC - max
Short-circuit current rating (high fault)
100 kA, 480 V, SCCR (UL/CSA)
25 kA, 600 V, SCCR (UL/CSA)
100 A, Class J, max. Fuse, SCCR (UL/CSA)
Rated operational power at AC-23A, 400 V, 50 Hz
Rated operational power at AC-23A, 500 V, 50 Hz
Rated operational power at AC-23A, 690 V, 50 Hz
Rated operational power at AC-3, 380/400 V, 50 Hz
Tightening torque
3.5 Nm, 6 mm², Screw terminals
31 lb-in, 10 AWG , Screw terminals
35.4 lb-in, 8 - 2 AWG , Screw terminals
44.3 lb-in, 1 - 2/0 AWG , Screw terminals
5 Nm, 50 - 70 mm², Screw terminals
4 Nm, 10 - 35 mm², Screw terminals
Uninterrupted current
Rated uninterrupted current Iu is specified for max. cross-section.
