E57EAL8T111SD 136252 EATON MOELLER Proximity switch, inductive, 1N/O, Sn 1mm, 3L, 10-30VDC, PNP, M8mm, M12 Ver maior
As imagens são só a título ilustrativo. Por favor, consulte a ficha técnica.

E57EAL8T111SD 136252 EATON MOELLER Proximity switch, inductive, 1N/O, Sn 1mm, 3L, 10-30VDC, PNP, M8mm, M12

E57EAL8T111SD

136252

EATON - MOELLER

Disponível

Envio hoje

Proximity switch, inductive, 1N/O, Sn=1mm, 3L, 10-30VDC, PNP, M8mm, M12

Mais detalhes


Sensores Indutivos

Sensors-EATON-MOELLER

E57 Miniature Series Inductive Sensors - EATON - MOELLER

* Produto novo em sua embalagem original com todas as garantias e certificações de EATON - MOELLER

QuantidadePreço
1+24,48 €
7+22,19 €
14+21,65 €
20+21,42 €
27+21,25 €
*Este preço é por unidade e mostra o valor líquido (excluindo impostos indirectos se aplicável).


Produtos relacionados

Mais informação



Delivery programme
Basic function
  Inductive Sensors
Product range
  E57 Miniatur Series
Connection
  3-wire
Design (outer dimensions)
  mmM8 x 1
Rated operational voltage
Ue 10 - 30 V DC
Rated switching distance
Snmm1
Type of mounting
  Flush
Switching type
  PNP
For connection of:
  Plug-in connection M12 x 1
Contacts

N/O = Normally open
  1 N/O
Material
  Stainless steel
Degree of Protection
  IP67
Technical data
General
Standards
  IEC/EN 60947-5
Ambient temperature
  -25 - +70
Mechanical shock resistance
 g30
Shock duration 11 ms
Degree of Protection
  IP67
Characteristics
Rated switching distance

Rated switching distance
Snmm1
Repetition accuracy of Sn
 %1
Temperature drift of Sn
 %10
Switching hysteresis of Sn
 %15
Rated operational voltage
Ue 10 - 30 V DC
Maximum load current
IemA< 200
Operating current in the switched state at 24 V DC
IbmA10
Voltage drop at Ie
UdV1.5
Switching Frequency
 Hz2000
Residual current through the load in the blocked state at 230 V AC and 24 V DC
IrmA0.01
Switching state display
 LEDRed
Protective functions
  Short-circuit protective device
Connection
  3-wire
Contacts

N/O = Normally open
  1 N/O
Style

Design (outer dimensions)
  mmM8 x 1
For connection of:
  Plug-in connection M12 x 1
Material
  Stainless steel
Design verification as per IEC/EN 61439(Show features)(Hide features)
Technical data for design verification

Operating ambient temperature min.
 °C-25
Operating ambient temperature max.
 °C70
Approvals
Product Standards  CE marking
Max. Voltage Rating  30 V DC
Degree of Protection  IEC: IP67; UL/CSA Type: -
Dimensions
>

Datasheet - PDF

Title:Language:Size:Type:
pdf-E57EAL8T111SD Proximity switch, inductive, 1N/O, Sn1mm, 3L, 10-30VDC, PNP, M8mm - EATON - E57EAL8T111SD - English144 Kbytespdf-E57EAL8T111SD Proximity switch, inductive, 1N/O, Sn1mm, 3L, 10-30VDC, PNP, M8mm - EATON - E57EAL8T111SD -
