NEBV0505 7TCA297120R0348 THOMAS AND BETTS EX 90 CURVED ELBOW NC25 M25 BLK
NEBV0505
7TCA297120R0348
THOMAS AND BETTS
10
EX 90 CURVED ELBOW NC25 M25 BLK
PMA cable protection
* Brand new product in its original packaging covered by the warranties and certifications provided by THOMAS AND BETTS
Best sellers
▲More info
▲- Extended Product Type:
- NEBV0505
- Product ID:
- 7TCA297120R0348
- EAN:
- 5011949239944
- Catalog Description:
- EX 90 CURVED ELBOW NC25 M25 BLK
- Long Description:
- Conduit Fitting, 90 Degree Curved Elbow with External Male Thread, Conduit Size 25mm, M25 Thread, Minimum Bore 23mm, Suitable for Unbraided Nylon Conduit, Approved for Zone 1 and 2, Zone 21 and 22, IP68 Rating, Modified Nylon 12 with Nickel Plated Threads, Black
Ordering
- EAN:
- 5011949239944
Dimensions
- Product Net Weight:
- .1lb
45.351 g
Container Information
- Package Level 1 Units:
- 10 piece
- Package Level 1 Width:
- 11.9 in
302 mm
- Package Level 1 Height:
- 7.9 in
201 mm
- Package Level 1 Depth / Length:
- 8.3 in
211 mm
- Package Level 2 Units:
- 100 piece
- Package Level 2 Width:
- 15.8 in
401 mm
- Package Level 2 Height:
- 11.9 in
302 mm
- Package Level 2 Depth / Length:
- 8.3 in
211 mm
Additional Information
- Application:
- For Indoor and Outdoor Applications
- Brand / Label:
- PMA
- Color:
- Black
- Insulation Class:
- IP68
- Material:
- Modified Nylon 12 with Nickel Plated Threads
- Number of Batteries:
- 0
- Product Name:
- NYLON EX FITTING
- Product Type:
- 90 Degree Curved Conduit Fitting with Male Thread
- Size:
- Conduit Size 25mm ; M25 Thread
- Special Functions:
- Nickel Plated Threads for Extra Stength
- Standards:
- ATEX:SEV15ATATEX0121, IECEX:IECEx SEV15.0009, Ex eb IIC, Ex tb IIIC
- Temperature Range:
- -20 to 85 °C
Certificates and Declarations (Document Number)
- Data Sheet, Technical Information:
- 9AKK106930A7765
- Declaration of Conformity - CE:
- 9AKK107680A0674
- Instructions and Manuals:
- NEBV0505
Classifications
- ETIM 6:
- EC001176 - Screw connection for corrugated plastic hose
- ETIM 7:
- EC001176 - Screw connection for corrugated plastic hose
- UNSPSC:
- 39121311
- WEEE Category:
- Product Not in WEEE Scope
- IDEA Granular Category Code (IGCC):
- 4441 >> Electrical fittings
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE THOMAS&BETTS EN.pdf | 15 Mbytes |
|
| 7TCA297120R0348 7TCA297120R0348 EN_7TCA297120R0348.pdf | 81 Kbytes |
|
