NEBV0404 7TCA297120R0347 THOMAS AND BETTS EX 90 CURVED ELBOW NC20 M20 BLK
NEBV0404
7TCA297120R0347
THOMAS AND BETTS
10
EX 90 CURVED ELBOW NC20 M20 BLK
PMA cable protection
Brand new product in its original packaging covered by the warranties and certifications provided by THOMAS AND BETTS
Best sellers
▲More info
▲- Extended Product Type:
- NEBV0404
- Product ID:
- 7TCA297120R0347
- EAN:
- 5011949239937
- Catalog Description:
- EX 90 CURVED ELBOW NC20 M20 BLK
- Long Description:
- Conduit Fitting, 90 Degree Curved Elbow with External Male Thread, Conduit Size 20mm, M20 Thread, Minimum Bore 17mm, Suitable for Unbraided Nylon Conduit, Approved for Zone 1 and 2, Zone 21 and 22, IP68 Rating, Modified Nylon 12 with Nickel Plated Threads, Black
Ordering
- EAN:
- 5011949239937
Dimensions
- Product Net Weight:
- .1lb
45.351 g
Container Information
- Package Level 1 Units:
- 10 piece
- Package Level 1 Width:
- 11.9 in
302 mm
- Package Level 1 Height:
- 7.9 in
201 mm
- Package Level 1 Depth / Length:
- 8.3 in
211 mm
- Package Level 2 Units:
- 160 piece
- Package Level 2 Width:
- 15.8 in
401 mm
- Package Level 2 Height:
- 11.9 in
302 mm
- Package Level 2 Depth / Length:
- 8.3 in
211 mm
Additional Information
- Application:
- For Indoor and Outdoor Applications
- Brand / Label:
- PMA
- Color:
- Black
- Insulation Class:
- IP68
- Material:
- Modified Nylon 12 with Nickel Plated Threads
- Number of Batteries:
- 0
- Product Name:
- NYLON EX FITTING
- Product Type:
- 90 Degree Curved Conduit Fitting with Male Thread
- Size:
- Conduit Size 20mm ; M20 Thread
- Special Functions:
- Nickel Plated Threads for Extra Stength
- Standards:
- ATEX:SEV15ATATEX0121, IECEX:IECEx SEV15.0009, Ex eb IIC, Ex tb IIIC
- Temperature Range:
- -20 to 85 °C
Certificates and Declarations (Document Number)
- Data Sheet, Technical Information:
- 9AKK106930A7765
- Declaration of Conformity - CE:
- 9AKK107680A0674
- Instructions and Manuals:
- NEBV0404
Classifications
- ETIM 6:
- EC001176 - Screw connection for corrugated plastic hose
- ETIM 7:
- EC001176 - Screw connection for corrugated plastic hose
- UNSPSC:
- 39121311
- WEEE Category:
- Product Not in WEEE Scope
- IDEA Granular Category Code (IGCC):
- 4441 >> Electrical fittings
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PMA CABLES PROTECTION EN.pdf | 7 Mbytes |
|
| PDF CATALOGUE THOMAS&BETTS EN.pdf | 18 Mbytes |
|
| NEBV0404 7TCA297120R0347 EN_7TCA297120R0347.pdf | 80 Kbytes |
|
