210219 7TAI029020R0007 THOMAS AND BETTS RING TERM CU 14-10 AWG 8 STUD
210219
7TAI029020R0007
THOMAS AND BETTS
1000
RING TERM CU 14-10 AWG #8 STUD
DRAGON T. TERMINAL RECTAN. 10,5MM2 M4
Installation, isolation and connection material > Solderless copper terminals for copper conductors
Terminals
Brand new product in its original packaging covered by the warranties and certifications provided by THOMAS AND BETTS
Best sellers
▲More info
▲- Extended Product Type:
- 210219
- Product ID:
- 7TAI029020R0007
- EAN:
- 5414363111764
- Catalog Description:
- RING TERM CU 14-10 AWG NO8 STUD
- Long Description:
- Insulation Piercing Magnet Wire Ring Terminal, Length 1.22 Inches, Width .41 Inches, Length of Teeth .56 Inches, Width of Teeth .38 Inches, Stud Size 8, Wire Range #14 AWG - #10 AWG 4,110 Circular Mil Area - 20,760 Circular Mil Area, Copper Alloy, Tin Plated
Ordering
- EAN:
- 5414363111764
- UPC:
- 786210839653
- Country of Origin:
- United States (US)
- Selling Unit of Measure:
- each
Container Information
- Package Level 1 Units:
- 250 piece
- Package Level 1 Width:
- 4.5 in
114 mm
- Package Level 1 Height:
- 3 in
76 mm
- Package Level 1 Depth / Length:
- 5 in
127 mm
- Package Level 2 Units:
- 1000 piece
- Package Level 2 Width:
- 9.625 in
244 mm
- Package Level 2 Height:
- 3.437 in
87 mm
- Package Level 2 Depth / Length:
- 10.75 in
273 mm
Additional Information
- Application:
- For aluminum to copper, aluminum to aluminum or copper to copper magnet wire connections.
- Brand / Label:
- Sta-Kon
- Effective Date:
- 19720711
- Material:
- Copper
- Product Name:
- STA-KON AND CATAMOUNT TERMINAL
- Product Type:
- Ring Terminal
- Special Functions:
- Designed to penetrate magnet wire insulation during application, eliminating the need for stripping, brazing, welding or other methods of joining magnet wire.
- Standards:
- UL E9809
- Sub Brand / Label:
- Dragon Tooth
Certificates and Declarations
- Data Sheet, Technical Information:
- 210219
Classifications
- ETIM 6:
- EC001052 - Solderless copper terminals for copper conductors
- ETIM 7:
- EC001052 - Solderless copper terminals for copper conductors
- ETIM 8:
- EC001052 - Solderless copper terminals for copper conductors
- UNSPSC:
- 39121432
- WEEE Category:
- Product Not in WEEE Scope
- IDEA Granular Category Code (IGCC):
- 4603 >> Electrical terminals
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE THOMAS&BETTS EN.pdf | 18 Mbytes |
|
| 210219 7TAI029020R0007 EN_7TAI029020R0007.pdf | 91 Kbytes |
|
