3TX4490-0W SIEMENS Surge suppressor Varistor for snapping on and as base element 127...240 V AC/150...250 V ..
3TX4490-0W
SIEMENS
Surge suppressor Varistor for snapping on and as base element 127...240 V AC/150...250 V DC for contactors size 0 and 1
Low-voltage industrial components > Surge voltage protection
CONTROL AND CONTACTORS > Function relays
* Brand new product in its original packaging covered by the warranties and certifications provided by SIEMENS
Best sellers
▲More info
▲ETIM: EC000197 - Surge voltage protection
| Value | Unit | |
|---|---|---|
| Model (EF000010) | Varistor (voltage-sensitive resistor) | |
| Rated voltage Ue at AC 50 Hz (EF007029) | ['115', '240'] | V |
| Rated voltage Ue at AC 60 Hz (EF007030) | ['115', '240'] | V |
| Rated voltage Ue at DC (EF007031) | ['150', '250'] | V |
| Voltage type (operating voltage) (EF005294) | AC/DC |
| Product | ||
| Article Number (Market Facing Number) | 3TX4490-0W | |
| Product Description | Surge suppressor Varistor for snapping on and as base element 127...240 V AC/150...250 V DC for contactors size 0 and 1 | |
| Product family | Not available | |
| Product Lifecycle (PLM) | PM410:Product cancellation | |
| PLM Effective Date | Product is cancelled since: 01.04.2020 | |
| Price data | ||
| Price Group | 41B | |
| Surcharge for Raw Materials | None | |
| Metal Factor | None | |
| Delivery information | ||
| Export Control Regulations | ECCN : N / AL : N | |
| Standard lead time ex-works | 15 Day/Days | |
| Net Weight (kg) | 0,027 Kg | |
| Product Dimensions (W x L x H) | Not available | |
| Packaging Dimension | 40,00 x 45,00 x 25,00 | |
| Package size unit of measure | MM | |
| Quantity Unit | 1 Piece | |
| Packaging Quantity | 1 | |
| Additional Product Information | ||
| EAN | 4011209054363 | |
| UPC | Not available | |
| Commodity Code | 85363010 | |
| LKZ_FDB/ CatalogID | NSE | |
| Product Group | 5809 | |
| Group Code | R711 | |
| Country of origin | Czech Republic | |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 | |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. | |
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |
| REACH Art. 33 Duty to inform according to the current list of candidates |
| |
| Classifications | ||
| Not available | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE SIEMENS EN.pdf | 120 Mbytes |
|
| 3TX4490-0W 3TX4490-0W EN_3TX4490-0W.pdf | 117 Kbytes |
|
