3SB2210-2EE01
SIEMENS
1
Selector switch, 16 mm, round, plastic, green, 3 switch positions I>O
Low-voltage industrial components > Selector switch, complete
CONTROL AND CONTACTORS > Commanding and signaling devices
* Brand new product in its original packaging covered by the warranties and certifications provided by SIEMENS
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Product | ||||||||||||||||||||||||||||||||||||||||
Article Number (Market Facing Number) | 3SB2210-2EE01 | |||||||||||||||||||||||||||||||||||||||
Product Description | Selector switch, 16 mm, round, plastic, green, 3 switch positions I>O<II, momentary contact type, Retraction from left and right, Actuating angle 2 x 50 degree, 1 NO, 1 NO | |||||||||||||||||||||||||||||||||||||||
Product family | Complete units | |||||||||||||||||||||||||||||||||||||||
Product Lifecycle (PLM) | PM300:Active Product | |||||||||||||||||||||||||||||||||||||||
Price data | ||||||||||||||||||||||||||||||||||||||||
Region Specific PriceGroup / Headquarter Price Group | 41J / 41J | |||||||||||||||||||||||||||||||||||||||
Surcharge for Raw Materials | None | |||||||||||||||||||||||||||||||||||||||
Metal Factor | LA------ | |||||||||||||||||||||||||||||||||||||||
Delivery information | ||||||||||||||||||||||||||||||||||||||||
Export Control Regulations | AL : N / ECCN : N | |||||||||||||||||||||||||||||||||||||||
Standard lead time ex-works | 10 Day/Days | |||||||||||||||||||||||||||||||||||||||
Net Weight (kg) | 0,028 Kg | |||||||||||||||||||||||||||||||||||||||
Packaging Dimension | 50,00 x 80,00 x 53,00 | |||||||||||||||||||||||||||||||||||||||
Package size unit of measure | MM | |||||||||||||||||||||||||||||||||||||||
Quantity Unit | 1 Piece | |||||||||||||||||||||||||||||||||||||||
Packaging Quantity | 1 | |||||||||||||||||||||||||||||||||||||||
Additional Product Information | ||||||||||||||||||||||||||||||||||||||||
EAN | 4011209092594 | |||||||||||||||||||||||||||||||||||||||
UPC | 754554865935 | |||||||||||||||||||||||||||||||||||||||
Commodity Code | 85365080 | |||||||||||||||||||||||||||||||||||||||
LKZ_FDB/ CatalogID | CC-IC10 | |||||||||||||||||||||||||||||||||||||||
Product Group | 5834 | |||||||||||||||||||||||||||||||||||||||
Group Code | R711 | |||||||||||||||||||||||||||||||||||||||
Country of origin | Czech Republic | |||||||||||||||||||||||||||||||||||||||
Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 | |||||||||||||||||||||||||||||||||||||||
Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | |||||||||||||||||||||||||||||||||||||||
WEEE (2012/19/EU) Take-Back Obligation | Yes | |||||||||||||||||||||||||||||||||||||||
REACH Art. 33 Duty to inform according to the current list of candidates |
| |||||||||||||||||||||||||||||||||||||||
Classifications | ||||||||||||||||||||||||||||||||||||||||
|
Value | Unit | |
---|---|---|
Degree of protection (NEMA) (EF011959) | - | |
Number of switch positions (EF000231) | 3 | |
Type of control element (EF006976) | Toggle | |
Suitable for illumination (EF001142) | false | |
With light source (EF005905) | - | |
Colour button (EF000190) | Green | |
Hole diameter (EF000079) | 16.0 | mm |
Width opening (EF004565) | 19.0 | mm |
Height opening (EF004778) | 17.0 | mm |
Switching function latching (EF007447) | FALSE | |
Spring-return (EF001407) | FALSE | |
Degree of protection (IP) (EF005474) | IP65 | |
Supply voltage (EF004127) | ['5', '250'] | V |
Number of contacts as normally open contact (EF008256) | 2 | |
Number of contacts as normally closed contact (EF008255) | 0 | |
Number of contacts as change-over contact (EF008257) | 0 | |
Type of electric connection (EF003961) | Flat plug-in connection | |
With front ring (EF006014) | true | |
Material front ring (EF005972) | Plastic | |
Colour front ring (EF002429) | Black |
Title: | Size: | Type: |
---|---|---|
PDF CATALOGUE SIEMENS EN.pdf | 120 Mbytes | |
3SB2210-2EE01 3SB2210-2EE01 EN_3SB2210-2EE01.pdf | 196 Kbytes |
