3RK1911-2BF02 SIEMENS ECOFAST Energy T clamping connector for feeder 6 mm2 View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

3RK1911-2BF02 SIEMENS ECOFAST Energy T clamping connector for feeder 6 mm2

3RK1911-2BF02

SIEMENS

ECOFAST Energy T clamping connector for feeder 6 mm2

ECOFAST TERMINAL IN T OF ENERGY P / DERIVATION 6MM2

More details


Low-voltage industrial components > Accessories/spare parts for low-voltage switch technology

CONTROL AND CONTACTORS > AS-Interface switchgear, SIMOCODE

Brand new product in its original packaging covered by the warranties and certifications provided by SIEMENS

Total: $347.55
Unit price: $347.55
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Technical data

ECOFAST Energy T clamping connector for feeder 6 mm2
General technical data
degree of pollution3
surge voltage resistance rated value6 000 V
protection class IPIP65
Substance Prohibitance (Date)05/01/2012
operating voltage rated value690 V
operational current at AC at 400 V rated value40 A
Ambient conditions
ambient temperature during operation-40 ... +125 °C
Installation/ mounting/ dimensions
height55 mm
width112 mm
length158 mm
Approvals Certificates

Downloads and manuals

General Product ApprovalEMCDeclaration of Conformity

CSA

Confirmation

UL

EAC

RCM

EC/EU-Declaration of Conformity

Declaration of Conformityother

UK Declaration of Conformity

Confirmation

Further information
Siemens has decided to exit the Russian market (see here).
Siemens is working on the renewal of the current EAC certificates.
Please contact your local Siemens office on the status of validity of the EAC certification if you intend to import or offer to supply these products to an EAC relevant market (other than the sanctioned EAEU member states Russia or Belarus).
Information on the packaging
Information- and Downloadcenter (Catalogs, Brochures,…)
Industry Mall (Online ordering system)
Cax online generator
Service&Support (Manuals, Certificates, Characteristics, FAQs,...)
Image database (product images, 2D dimension drawings, 3D models, device circuit diagrams, EPLAN macros, ...)
last modified:12/23/2020
Date
6/29/2023		Subject to change without notice
© Copyright Siemens 2023


Additional data

Product
Article Number (Market Facing Number)3RK1911-2BF02
Product DescriptionECOFAST Energy T clamping connector for feeder 6 mm2
Product familyOrdering Data Overview
Product Lifecycle (PLM)PM300:Active Product
Price data
Region Specific PriceGroup / Headquarter Price Group42D / 42D
Surcharge for Raw MaterialsNone
Metal FactorNone
Delivery information
Export Control RegulationsAL : N / ECCN : N
Standard lead time ex-works5 Day/Days
Net Weight (kg)0,344 Kg
Packaging Dimension120,00 x 160,00 x 63,00
Package size unit of measureMM
Quantity Unit1 Piece
Packaging Quantity1
Additional Product Information
EAN4011209613010
UPC040892924909
Commodity Code85366990
LKZ_FDB/ CatalogIDCC-IC10
Product Group3723
Group CodeR711
Country of originGermany
Compliance with the substance restrictions according to RoHS directiveSince: 01.05.2012
Product classA: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back ObligationYes
REACH Art. 33 Duty to inform according to the current list of candidates
There is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly.
Classifications
VersionClassification
eClass1227-37-09-92
eClass627-37-09-92
eClass7.127-37-09-92
eClass827-37-09-92
eClass927-37-09-92
eClass9.127-37-09-92
ETIM7EC002498
ETIM8EC002498
UNSPSC1539-12-15-21

ETIM data

ETIM: EC002498 - Accessories/spare parts for low-voltage switch technology

Value Unit
Type of accessory/spare part (EF000215) -



Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGUE SIEMENS EN.pdf 120 Mbytes
PDF CATALOGUE SIEMENS EN.pdf 104 Mbytes
3RK1911-2BF02 3RK1911-2BF02 EN_3RK1911-2BF02.pdf 235 Kbytes 3RK1911-2BF02 3RK1911-2BF02 EN_3RK1911-2BF02.pdf
