ZFKDSA 1,5-5,08- 3 1891506 PHOENIX CONTACT PCB terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

ZFKDSA 1,5-5,08- 3 1891506 PHOENIX CONTACT PCB terminal block

ZFKDSA 1,5-5,08- 3

1891506

PHOENIX_CONTACT

50

Available Ship on today

New orders for this item will be processed from April 13

PCB terminal block

More details


PCB Connectors (PCC)

* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

More info



Key Commercial Data

Orderkey 1891506
Packing unit 50 pc
Minimum order quantity50 pc
NoteMade to Order (non-returnable)
GTIN4017918416386
Weight per Piece (excluding packing)4.030 g
Custom tariff number85369010
Country of originGR (Greece)

Dimensions

Length [ l ]16.9 mm
Pitch5.08 mm
Dimension a10.16 mm
Width [ w ]17.78 mm
Height14.2 mm
Height [ h ]17.7 mm
Solder pin [P]3.5 mm
Pin spacing5.08 mm
Hole diameter1.3 mm

General

Range of articlesZFKDS(A) 1,5
Insulating material groupI
Rated surge voltage (III/3)4 kV
Rated surge voltage (III/2)4 kV
Rated surge voltage (II/2)4 kV
Rated voltage (III/3)250 V
Rated voltage (III/2)400 V
Rated voltage (II/2)630 V
Connection in acc. with standardEN-VDE
Nominal current IN16 A
Nominal cross section1.5 mm²
Maximum load current16 A
Insulating materialPA
Solder pin surface
Flammability rating according to UL 94V0
Stripping length7.5 mm
Number of positions3

Connection data

Conductor cross section AWG min.24
Conductor cross section AWG max.14

Standards and Regulations

Connection in acc. with standardEN-VDE
CSA
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
