UM-D25SUB/F/M/16DO-RELS/SC049 2905752 PHOENIX CONTACT 16-channel digital output module with spring-cage conn..
UM-D25SUB/F/M/16DO-RELS/SC049
2905752
PHOENIX_CONTACT
30
16-channel digital output module with spring-cage connection and 25-pos. D-SUB miniature socket strip and 25-pos. D-SUB miniature pin strip, plug-in relay base for fitting 60 V DC or 24 V DC optocouplers, module width: 365 mm
INTERFACE Components (IF)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| General | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
| Utilization restriction | |
| EMC note | EMC: class A product, see manufacturer's declaration in the download area |
| Product type | Relay Module |
| Insulation characteristics | |
| Insulation | Reinforced insulation |
| Insulation characteristics: Air clearances and creepage distances, input/output | |
| Insulation | Reinforced insulation |
| Overvoltage category | III |
| Pollution degree | 2 |
| Insulation characteristics: Air and creepage distances, output/output | |
| Insulation | Basic insulation |
| Overvoltage category | III |
| Pollution degree | 2 |
| Air clearances and creepage distances, input/output | |
| Rated insulation voltage | 300 V |
| Rated surge voltage | 6 kV (1.2/50 μs) |
| Air and creepage distances, output/output | |
| Rated insulation voltage | 300 V |
| Rated surge voltage | 4 kV (1.2/50 μs) |
| Nominal input voltage UN | 24 V |
| Input voltage range in reference to UN | 0.9 ... 1.1 |
| Typical input current at UN | 1 A (per channel) |
| Protective circuit | Freewheeling, LED; Freewheeling diode, LED |
| Switching | |
| Contact switching type | Single contact, 1 changeover contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Limiting continuous current | 2 A (per channel) |
| Controller level | |
| Connection in acc. with standard | DIN 41652/IEC 60807-2 |
| Connection method | D-SUB-25 male/D-SUB-25 female |
| Number of positions | 25 |
| Field level | |
| Connection method | Spring-cage connection |
| Conductor cross section rigid | 0.2 mm² ... 4 mm² |
| Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
| Conductor cross section AWG | 24 ... 12 |
| Width | 365 mm |
| Height | 143 mm |
| Depth | 68 mm |
| Ambient conditions | |
| Degree of protection | IP00 |
| Degree of protection (Installation location) | ≥ IP54 (Installation location) |
| Ambient temperature (operation) | -20 °C ... 50 °C |
| Altitude | ≤ 2000 m |
| Air clearances and creepage distances, input/output | |
| Standards/regulations | DIN EN 50178: 1998-04 |
| Air and creepage distances, output/output | |
| Standards/regulations | DIN EN 50178: 1998-04 |
| Mounting type | DIN rail mounting |
| Assembly instructions | in rows with zero spacing |
| Mounting position | any |
