TVFKC 1,5/ 8-ST BD:A-H
1799219
PHOENIX_CONTACT
1000
Connector for printed circuit board, nominal current: 10 A, number of poles: 8, pitch: 5 mm, connection type: spring clamp push-in, color: green, surface contacts: Tin
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Connector for printed circuit board, nominal current: 10 A, voltage and sizing (III/2): 320 V, number of poles: 8, pitch: 5 mm, connection type: spring clamp push-in, color: green, surface contacts: Tin
Key order | One million seven hundred ninety nine thousand two hundred nineteen |
---|---|
Packing unit | 50 pcs |
Key selling | AAAFBB - |
Minimum order quantity | 1000 pcs |
EAN | Four trillion forty six billion three hundred fifty six million six hundred fifty seven thousand four hundred eighty eight |
Unit weight (excluding packaging) | 11,999 g |
Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
Country of origin | PL (Poland) |
Length [ l ] | 23,3 mm |
---|---|
Width [ w ] | 40 mm |
Height [ h ] | 15 mm |
Step | 5 mm |
Average | 35 mm |
Family of articles | TVFKC 1,5/..-ST |
---|---|
Number of poles | Eight |
Type of connection | Connection by spring loaded push-in |
Tension and sizing (III/3) | 250 V |
Connection according to standard | EN-VDE |
Nominal current IN | 10 To |
Nominal cross section | 1.5 mm2 |
Core cross-section rigid min. | 0,2 mm2 |
---|---|
Section of conductor rigid max. | 1.5 mm2 |
Section of flexible conductor, min. | 0,2 mm2 |
Section of flexible conductor max. | 1.5 mm2 |
Section of flexible conductor with toe cap, without plastic sleeve min. | 0.25 mm2 |
Section of flexible conductor with toe cap, without plastic sleeve max. | 1.5 mm2 |
Section of flexible conductor with toe, with plastic sleeve min. | 0.25 mm2 |
Section of flexible conductor with toe, with plastic sleeve max. | 1.5 mm2 |
Section of conductor AWG min. | Twenty four |
Section of conductor AWG max. | Sixteen |
Connection according to standard | EN-VDE |
---|
China RoHS | Space of time for the intended use: unlimited = FEUP-e |
---|---|
No dangerous substances above the thresholds |
eCl@ss 4.0 | 272607xx |
---|---|
eCl@ss 4.1 | Twenty seven million two hundred sixty thousand seven hundred one |
eCl@ss 5.0 | Twenty seven million two hundred sixty thousand seven hundred one |
eCl@ss 5.1 | Twenty seven million two hundred sixty thousand seven hundred |
eCl@ss 6.0 | Twenty seven million two hundred sixty thousand seven hundred |
eCl@ss 7.0 | Twenty seven million four hundred forty thousand three hundred nine |
eCl@ss 8.0 | Twenty seven million four hundred forty thousand three hundred nine |
eCl@ss 9.0 | Twenty seven million four hundred forty thousand three hundred nine |
ETIM 3.0 | EC001121 |
---|---|
ETIM 4.0 | EC002638 |
ETIM 5.0 | EC002638 |
ETIM 6.0 | EC002638 |
ETIM 7.0 | EC002638 |
UNSPSC 6.01 | Thirty million two hundred eleven thousand eight hundred ten |
---|---|
UNSPSC 7.0901 | Thirty nine million one hundred twenty one thousand four hundred nine |
UNSPSC 11 | Thirty nine million one hundred twenty one thousand four hundred nine |
UNSPSC 12.01 | Thirty nine million one hundred twenty one thousand four hundred nine |
UNSPSC 13.2 | Thirty nine million one hundred twenty one thousand four hundred nine |
Title: | Size: | Type: |
---|---|---|
PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
