TU-16S1N128UD2X 1242651 PHOENIX CONTACT Plug-in connector. for cables
TU-16S1N128UD2X
1242651
PHOENIX_CONTACT
10
Plug-in connector. for cables
M23, Cable Connector, Series: TU, Straight, Shielded: Yes, Bayonet Lock, No. of Poles: 16, Direction of Rotation: Standard, Contact Connection Type: Female, Soldering Cup, Cable Diameter Range: 2 mm ... 14.5 mm, coding: N, RoHS II lead-free article without exception 6c (Pb< 0.1%)
Home > PHOENIX CONTACT
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| Product Type | Circular connector (cable side) |
| Insulating body | |
| Codification | N |
| Plug Cycles | 50 |
| Connection type | Soldering cup |
| Contact Switching Type | Female |
| application | Signal |
| Number of poles | 16 |
| Direction of rotation | Standard |
| Plug Face | 16 |
| Contact DiameterPower Contacts | 1 mm |
| Braided yarn sectionPower Contactsmin. | 0.08 mm² |
| Braided yarn sectionPower ContactsMax. | 1 mm² |
| Rated CurrentPower Contacts | 8 A |
| Nominal voltage | 48 V AC |
| 74 V DC | |
| Dimensioning Transient Voltage | 1.5 kV |
| Surge Category | Iii |
| Degree of pollution | 3 |
| Housing | |
| Shell material | Metal |
| Lock Type | Bayonet lock |
| Pg Cable Glands | without |
| Protection Index (inserted) | IP67 |
| Thread Type | M23 |
| Meeting | |
| Cable Outer Diameter | 2 mm ... 14.5 mm |
| Gasket material | FPM |
