TU-12S1N8AWB00X 1242045 PHOENIX CONTACT M23, Conect. plug. to be apar. front wall, series: TU, straight, shi..
TU-12S1N8AWB00X
1242045
PHOENIX_CONTACT
40
M23, Conect. plug. to be apar. front wall, series: TU, straight, shielded: yes, Bayonet lock, No. of poles: 12, Direction of rotation: Standard, contact connection type: Female, Crimp connection, Axial O-ring, 4x Ø 3.2, Min. wall thickness: 1.5 mm, coding: N, The item does not contain lead according to the RoHS II directive without exception 6c (Pb<.; 0.1 %)
Connect. plug in. to apar. wall delant.
M23, Device connector front mounting, series: TU, straight, shielded: yes, Bayonet locking, No. of pos.: 12, Direction of rotation: Standard, contact connection type: Socket, Crimp connection, Axial O-ring, 4x Ø 3.2, Panel thickness min.: 1.5 mm, coding: N, Item is lead-free in accordance with RoHS II without Exemption 6c (Pb <0.1%)
Home > PHOENIX CONTACT
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| Product type | Circular connectors (device side) |
| Insulating body | |
| Note | Order information: Order crimp contacts Ø 1 mm separately |
| Coding | N |
| Connection method | Crimp connection |
| Contact switching type | Socket |
| Application | Signal |
| Number of positions | 12 |
| Direction of rotation | Standard |
| Connection profile | 12 |
| Contact diameterPower contacts | 1 mm |
| Rated currentPower contacts | 8 A |
| Rated voltage | 48 V AC |
| 74 V DC | |
| Rated surge voltage | 1.5 kV |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Housing | |
| Housing material | Metal |
| Type of locking | Bayonet locking |
| Pg screw connection | none |
| Degree of protection (plugged in) | IP67 |
| Thread type | M23 |
