TU-12S1N128UDU 1605964 PHOENIX CONTACT Cable connector
TU-12S1N128UDU
1605964
PHOENIX_CONTACT
10
Product on demand only, returns will not be accepted.
Cable connector
M23, Plug connector. for cables, TU, straight, shielded: yes, Bayonet lock, No. of poles: 12, Direction of rotation: Standard, contact type: Female, Solder connection, cable diameter range: 2 mm ... 14.5 mm, coding:N, Alternative product according to RoHS II without exception 6c (Pb< 0.1%) item code: 1242046
M23, Cable connector, series: TU, straight, shielded: yes, Bayonet locking, Number of poles: 12, Direction of rotation: standard, contact connection type: Female, Hand-soldered, cable diameter: 2 mm 14.5 mm, coding: N, Alternative product according to RoHS II without exception 6c (Pb < 0.1 %) Art. No.: 1242041
Connectors > Circular connector for field assembly (industrial connector)
Field Device Connectors (FDC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Key Commercial Data
| Orderkey | 1605964 |
|---|---|
| Packing unit | 10 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4046356256209 |
| Weight per Piece (excluding packing) | 102.570 g |
| Custom tariff number | 85366990 |
| Country of origin | DE (Germany) |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
eCl@ss 4.0272607xxeCl@ss 4.127260701eCl@ss 5.027260701eCl@ss 5.127260700eCl@ss 6.027260700eCl@ss 7.027440102eCl@ss 8.027440102eCl@ss 9.027440103
| Feature Name | Feature Value |
|---|---|
| Number of data contacts (EF012232) | 0 |
| Number of power contacts (EF012216) | 0 |
| Type of locking (EF000208) | Other |
| With protective conductor (EF007468) | No |
| Screened (EF000881) | No |
| With status indication (EF001602) | No |
