TU-06P1NC2WB5DX 1245353 PHOENIX CONTACT M23, Conect. plug. to be apar. front wall, series: TU, straight, shi..
TU-06P1NC2WB5DX
1245353
PHOENIX_CONTACT
M23, Conect. plug. to be apar. front wall, series: TU, straight, shielded: yes, Bayonet lock, No. of poles: 6, Direction of rotation: Standard, contact connection type: Male, Solder connection, Axial O-ring, 4x Ø 3.2, Min. wall thickness: 1.5 mm, coding: N, The item does not contain lead according to the RoHS II directive without exception 6c (Pb<.; 0.1 %)
M23, Conect. plug. for apar. Wall of the Tower.
M23, Device connector front mounting, series: TU, straight, shielded: yes, Bayonet locking, No. of pos.: 6, Direction of rotation: Standard, contact connection type: Pin, Solder-in connection, Axial O-ring, 4x Ø 3.2, Panel thickness min.: 1.5 mm, coding: N, Item is lead-free in accordance with RoHS II without Exemption 6c (Pb <0.1%)
Home > PHOENIX CONTACT
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| Product type | Circular connectors (device side) |
| Flammability rating according to UL 94 | V0 |
| Insulating body | |
| Coding | N |
| Insertion/withdrawal cycles | 100 |
| Connection method | Solder-in connection |
| Contact switching type | Pin |
| Application | Signal |
| Number of positions | 6 |
| Direction of rotation | Standard |
| Connection profile | 6 |
| Contact diameterPower contacts | 2 mm |
| Rated currentPower contacts | 20 A |
| Rated surge voltage | 1.5 kV |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Housing | |
| Housing material | Metal |
| Type of locking | Bayonet locking |
| Pg screw connection | none |
| Degree of protection (plugged in) | IP67 |
| Thread type | M23 |
| Feature Name | Feature Value |
|---|---|
| Number of data contacts (EF012232) | 0 |
| Number of power contacts (EF012216) | 0 |
| Type of locking (EF000208) | Other |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| With protective conductor (EF007468) | No |
| Screened (EF000881) | No |
| With status indication (EF001602) | No |
