TC-2KS40-AI16-EX2-PR-CSTM 2905931 PHOENIX CONTACT Termination Carrier for connecting 16 MACX Analog Ex i sig..
TC-2KS40-AI16-EX2-PR-CSTM
2905931
PHOENIX_CONTACT
10
Termination Carrier for connecting 16 MACX Analog Ex i signal conditioners with double output to analog input cards of the Yokogawa Stardom TM via two KS40 connectors, 40-pos. Suitable for Yokogawa card NFAI143.
INTERFACE Components (IF)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲| General | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
| Product type | Module carrier |
| Insulation characteristics | |
| Insulation | Basic insulation |
| Insulation characteristics: Air clearances and creepage distances | |
| Insulation | Basic insulation |
| Overvoltage category | III |
| Pollution degree | 2 |
| Max. permissible current | 1 A (Signal/channel) |
| Nominal voltage UN | < 50 V DC (Per signal/channel) |
| Air clearances and creepage distances | |
| Rated insulation voltage | 50 V |
| Rated surge voltage | 0.5 kV |
| Supported controller YOKOGAWA STARDOM | |
| Suitable I/O card | NFAI143 |
| Supply | |
| Fuse | 2x 2.5 A on PCB, slow-blow (replaceable) |
| Input current | ≤ 2 A |
| Redundant supply | yes, decoupled from diodes |
| Polarization and surge protection | Yes |
| Output name | Switching output |
| Contact switching type | 1 N/C contact (alarm = open) |
| Maximum switching voltage | 30 V DC (2 A) |
| 33 V AC (2 A) | |
| Power supply | |
| Connection method | Screw connection |
| Stripping length | 7 mm |
| Number of connections | 1 |
| Number of positions | 6 |
| Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
| Conductor cross section flexible | 0.14 mm² ... 2.5 mm² |
| Conductor cross section AWG | 24 ... 12 |
| Controller level | |
| Connection method | Yokogawa KS-compatible |
| Number of connections | 2 |
| Number of positions | 40 |
| Status display | 2x green LEDs (PWR1 and PWR2) |
| Width | 322 mm |
| Height | 170 mm |
| Depth | 160 mm |
| Flammability rating according to UL 94 | V0 |
| Ambient conditions | |
| Degree of protection | IP00 |
| Ambient temperature (operation) | -20 °C ... 70 °C (For use at an ambient temperature of up to 70°C: the MACX MCR-SL-RPSSI-2I modules must be mounted 5 mm apart. Use the CLIPFIX 35-5 end brackets provided as spacers.) |
| Ambient temperature (storage/transport) | -40 °C ... 80 °C (Please observe module specifications) |
| Altitude | ≤ 2000 m |
| Permissible humidity (operation) | 5 % ... 95 % (non-condensing) |
| Shock | 15g, according to IEC˽60068-2-27 |
| Vibration (operation) | 2g, according to IEC 60068-2-6 |
| UL, USA/Canada | |
| Identification | UL 61010 Listed |
| Class I, Div. 2, Groups A, B, C, D T4 | |
| Class I, Zone 2, Group IIC | |
| Air clearances and creepage distances | |
| Standards/regulations | DIN EN 50178 |
| Mounting type | DIN rail mounting |
| Assembly instructions | No end clamp |
| Mounting position | vertical, horizontal |
