TC-06S1N8AT0EQX 1242633 PHOENIX CONTACT M23, Cable connector, angled, Bayonet lock, No. of poles: 6, Directi..
TC-06S1N8AT0EQX
1242633
PHOENIX_CONTACT
M23, Cable connector, angled, Bayonet lock, No. of poles: 6, Direction of rotation: Standard, type of contact connection: Female, Crimp connection, cable diameter range: 3 mm ... 10.5 mm, coding: N, The item does not contain lead according to the RoHS II directive without exception 6c (Pb<.; 0.1%)
M23, Plug connector. for cables
M23, Cable connector, angled, Bayonet lock, No. of poles: 6, Direction of rotation: Standard, contact connection type: Female, Crimp connection, cable diameter range: 3 mm ... 10.5 mm, encoding: N, Item is lead-free according to RoHS II without exception 6c (Pb< 0.1%)
Home > PHOENIX CONTACT
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| General | Crimped contacts Ø 2 mm must be ordered separately |
| Product Type | Circular connector (cable side) |
| Insulating body | |
| Observation | Order note: Crimped contacts Ø 2 mm must be ordered separately |
| Codification | N |
| Connection type | Crimp connection |
| Contact Switching Type | Female |
| application | Signal |
| Number of poles | 6 |
| Direction of rotation | Standard |
| Plug Face | 6 |
| Contact DiameterPower Contacts | 2 mm |
| Rated CurrentPower Contacts | 20 A |
| Nominal voltage | 48 V AC |
| 74 V DC | |
| Dimensioning Transient Voltage | 1.5 kV |
| Surge Category | Iii |
| Degree of pollution | 3 |
| Housing | |
| Lock Type | Bayonet lock |
| Protection Index (inserted) | IP67 |
| Thread Type | M23 |
| Meeting | |
| Cable Outer Diameter | 3 mm ... 10.5 mm |
| Gasket material | NBR |
| Feature Name | Feature Value |
|---|---|
| Number of data contacts (EF012232) | 0 |
| Number of power contacts (EF012216) | 0 |
| Type of locking (EF000208) | Other |
| With protective conductor (EF007468) | No |
| Screened (EF000881) | No |
| With status indication (EF001602) | No |
