SPT 5/ 4-V-7,5-ZB BK 1013210 PHOENIX CONTACT Terminal for printed circuit board, rated voltage: 1000 V, pitc..
SPT 5/ 4-V-7,5-ZB BK
1013210
PHOENIX_CONTACT
50
Terminal for printed circuit board, rated voltage: 1000 V, pitch: 7.5 mm, number of poles: 4, type of connection: spring clamp push-in, mounting: Soldering by wave, color: black
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Terminal for printed circuits, nominal current: 41 A, rated voltage: 1000 V, pitch: 7.5 mm, number of poles: 4, connection: spring-clamp Connection Push-in, mounting: Soldering wave, the direction of connecting the conductor/tab: 90 °, color: black
Commercial data
| The code for the order | One million thirteen thousand two hundred ten |
|---|---|
| Pieces/pack. | 50 PCS |
| Sales key | AABCAA - |
| The amount of minimum order | 50 PCS |
| GTIN | Four trillion fifty five billion six hundred twenty six million four hundred ninety one thousand four hundred fifty five |
| Weight per piece (package included) | 13,918 g |
| Number customs tariff | Eighty five million three hundred sixty nine thousand ten |
Features article
| Abbreviation | Terminal for printed circuits |
|---|---|
| Family article | SPT 5/..-V |
| Step | 7.5 mm |
| N. of poles | Four |
| Link | Spring-clamp connection Push-in |
| Type of mounting | Welding waves |
| Layout-pin | Pinning zig-zag W |
| Number of floors | One |
| Number links | Four |
| The number of potential | Four |
Electrical data
| Current sizing | 41 To |
|---|---|
| Rated insulation voltage nominal output voltage (III/2) | 1000 V |
| Surge voltage strength (III/2) | 8 kV |
Data link
| Conductor cross section, rigid | 0.2 mm2 ... 10 mm2 |
|---|---|
| Conductor cross section flexible | 0.2 mm2 ... 6 mm2 |
| Conductor cross-section AWG / kcmil | 24 ... 8 |
| Conductor cross-section flexible with crimp connector without collar plastic | 0.25 mm2 ... 6 mm2 |
| Conductor cross section flexible with crimp connector mounted collar and insulation | 0.25 mm2 ... 4 mm2 |
| 2 wires of identical section flexible with TWIN collar and plastic | 0.25 mm2 ... 1.5 mm2 |
| The length of the stretch from the strip | 15 mm |
Guidance material - contacts
| Note | Compliant with WEEE/RoHS, without materials filiform according to IEC 60068-2-82/JEDEC JESD 201 |
|---|---|
| Contact material | Alloy Cu |
| Surface finish | tinning galvanic |
| The metal surface of the point of connection (surface layer) | Tin (4 - 8 ám Sn) |
| The metal surface area of the weld (surface layer) | Tin (4 - 8 ám Sn) |
Guidance material - housing
| Insulating material | PA |
|---|---|
| Group insulating material | The |
| CTI according to IEC 60112 | Six hundred |
| Class behaviour according to UL 94 | V0 |
| Index of flammability of the filament GWFI according to EN 60695-2-12 | Eight hundred fifty |
| Ignition temperature of the filament GWIT according to EN 60695-2-13 | Seven hundred seventy five |
| Temperature of test for Brinell hardness in accordance with EN 60695-10-2 | 125 °C |
Shares relative to the product
| Dimensioned drawing | |
|---|---|
| Length [ l ] | 18.5 mm |
| Width [ w ] | 31,8 mm |
| Height [ h ] | 19 mm |
| Step | 7.5 mm |
| Height (without pin for welding) | 14.4 mm |
| Length of pin [P] | 4.6 mm |
| Distance shanks | 14 mm |
| The size of the shanks | 1.7 x 0.8 mm |
| Measure | 22.5 mm |
Dimensions printed circuit board design
| Hole diameter | 2.1 mm |
|---|---|
| Distance shanks | 14 mm |
Data packaging
| Packaging | packed in carton |
|---|---|
| Fifty | |
| Names packs | Pieces |
Environmental conditions
| Ambient temperature (transport and storage) | -40 °C ... 70 °C |
|---|---|
| Ambient temperature (assembly) | -5 °C ... 100 °C |
| Ambient temperature (operation) | -40 °C (In function of the curve of derating/load current allowed) |
Attack and methods of connection
| Connection test | DIN EN 60998-2-2 VDE (0613-2-2):2005-03 |
|---|---|
| Result of the test | Control passed |
| Proof of the integrity and stability of the conductors | DIN EN 60998-2-2 VDE (0613-2-2):2005-03 |
| Control passed |
Tensile test
| Tensile test | DIN EN 60998-2-2 VDE (0613-2-2):2005-03 |
|---|---|
| Control passed | |
| Conductor cross section / type of conductor / tensile strength | 0.2 mm2 / solid / > 10 N |
| 0.2 mm2 / flexible / > 10 N | |
| 10 mm2 / solid / > 90 N | |
| 6 mm2 / flexible / > 80 N |
Electrical controls
| Current sizing | 41 To |
|---|---|
| Rated insulation voltage nominal output voltage (III/2) | 1000 V |
| Surge voltage strength (III/2) | 8 kV |
Distances in the air and lines of flight
| Group insulating material | The |
|---|---|
| Rated insulation voltage nominal output voltage (III/3) | 800 V |
| Rated insulation voltage nominal output voltage (III/2) | 1000 V |
| Rated insulation voltage nominal output voltage (II/2) | 1000 V |
| Surge voltage strength (III/3) | 8 kV |
| Surge voltage strength (III/2) | 8 kV |
| Surge voltage strength (II/2) | 6 kV |
Test vibration
| Resistance against aging, humidity, penetration of solid foreign bodies and water | Control passed DIN EN 60998-1 (VDE 0613-1):2005-03 168 h/100 °C 48 h/30 °C/92 % |
|---|---|
| Result of the test | Control passed |
| Test specification | DIN EN 60998-1 (VDE 0613-1):2005-03 |
| Dry heat | 168 h/100 °C |
| Moist heat | 48 h/30 °C/92 % |
Resistance against aging, humidity, penetration of solid bodies
| Result of the test | Control passed |
|---|---|
| Test specification | DIN EN 60998-1 (VDE 0613-1):2005-03 |
| Dry heat | 168 h/100 °C |
| Moist heat | 48 h/30 °C/92 % |
Environmental Product Compliance
| China RoHS | Period for proper use: unlimited = EFUP-and |
|---|---|
| Any hazardous substances above the threshold values |
Rankings
eCl@ss
| eCl@ss 5.1 | Twenty seven million two hundred sixty one thousand one hundred |
|---|---|
| eCl@ss 6.0 | Twenty seven million two hundred sixty one thousand one hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand four hundred one |
ETIM
| ETIM 5.0 | EC002643 |
|---|---|
| ETIM 6.0 | EC002643 |
| ETIM 7.0 | EC002643 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
