SPT 2,5/ 1-H-5,0 SWO 1832917 PHOENIX CONTACT PCB terminal block, nominal current: 24 A, nom. voltage: 400 V,..
SPT 2,5/ 1-H-5,0 SWO
1832917
PHOENIX_CONTACT
100
PCB terminal block, nominal current: 24 A, nom. voltage: 400 V, pitch: 5 mm, number of positions: 1, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Data commercial
| Key order | One million eight hundred thirty two thousand nine hundred seventeen |
|---|---|
| Packing unit | 100 pcs |
| Key selling | AAACBA - |
| Minimum order quantity | 100 pcs |
| EAN | Four trillion forty six billion three hundred fifty six million nine hundred twelve thousand nine hundred forty five |
| Unit weight (excluding packaging) | 1,321 g |
| Tariff number tariff | Eighty five million three hundred sixty nine thousand ten |
| Country of origin | PL (Poland) |
- Drawings
- Characteristic data electrical
- Material data - contact
- Product dimensions
- Indications of packing
- Environmental conditions
- Tensile test
- Lines of flight and air spaces
- Test vibration
- Standards and specifications
- Ratings
- Properties of the article
- Ability conex.
- Material data - housing
- Dimensions for the design of the printed circuit board
- General indications of product
- Connection and method of connection
- Electrical testing
- Took place. calent.
- Resistance to aging, moisture and the penetration of solid objects
- Environmental Product Compliance
Properties of the article
| Abbreviation | Terminal for printed circuit board |
|---|---|
| Family of articles | SPT 2,5/..-H |
| Step | 5 mm |
| Number of poles | One |
| Type of connection | Connection by spring loaded push-in |
| Mounting type | Wave soldering |
| Design of the pin | Available pin dual linear |
| Number of floors | One |
| Number of connections | One |
| Number of potential | One |
Characteristic data electrical
| Rated current | 24 To |
|---|---|
| Rated voltage | 400 V |
| Tension sizing | 250 V |
| Tension and sizing (III/2) | 400 V |
| Tension and sizing (II/2) | 630 V |
| Transient voltage design (III/3) | 4 kV |
| Transient voltage design (III/2) | 4 kV |
| Transient voltage design (II/2) | 4 kV |
Ability conex.
| Type of connection | Connection by spring loaded push-in |
|---|---|
| Section of conductor rigid | 0,2 mm2 ... 4 mm2 |
| Section of flexible conductor | 0,2 mm2 ... 2.5 mm2 |
| Section of conductor AWG / kcmil | 24 ... 12 |
| Section of flexible conductor with toe cap, without plastic sleeve | 0.25 mm2 ... 2.5 mm2 (Length desaislar 8 mm) |
| Section of flexible conductor with toe, with plastic sleeve | 0.25 mm2 ... 1.5 mm2 (Length desaislar 8 mm) |
| Length of peeling | 10 mm |
Material data - contact
| Observation | According to WEEE/RoHS, without filaments according to IEC 60068-2-82/JEDEC JESD 201 |
|---|---|
| Material contact | Cu alloy |
| Characteristics of the surface | tinning of malleable cast iron |
| Metal surface of the point of embornaje (top layer) | Tin (4 - 8 ám Sn) |
| Metal surface area of solder (upper layer) | Tin (4 - 8 ám Sn) |
Material data - housing
| Color housing | green (6021) |
|---|---|
| Isolation | PA |
| Group insulating material | I |
| CTI according to IEC 60112 | Six hundred |
| Class of flammability according to UL 94 | V0 |
| Number of flammability of filaments GWFI according to en 60695-2-12 | Eight hundred fifty |
| Ignition temperature of filaments GWIT according to en 60695-2-13 | Seven hundred seventy five |
| Temperature test of the hardness for the balls according to en 60695-10-2 | 125 °C |
Product dimensions
| Outline dimensions |  |
|---|---|
| Length [ l ] | 14,4 mm |
| Width [ w ] | 5 mm |
| Height [ h ] | 16 mm |
| Step | 5 mm |
| Height of building (height without the shank of soldering) | 13.5 mm |
| Length of pin [P] | 2.5 mm |
| Separation between rods | 8,2 mm |
| Dimensions of pin | 0.8 x 0.8 mm |
Dimensions for the design of the printed circuit board
| Diameter hole | 1.1 mm |
|---|---|
| Separation between rods | 8,2 mm |
Indications of packing
| Type of packaging | packaged in box |
|---|---|
| Packing unit | One hundred |
| Designation packing Units | Units |
General indications of product
| Type of observation | Note on the application |
|---|---|
| Observation | Rated voltage of insulation with the piece aumentadora of step RZ-SPT-2,5-2,5: 400 V (III/3), 630 V (III/2), 1000 V (II/2) RZ-SPT-2,5-5,0: 630 V (III/3), 800 V (III/2), 1000 V (II/2) |
Environmental conditions
| Ambient temperature (storage / transport) | -40 °C ... 70 °C |
|---|---|
| Ambient temperature (assembly) | -5 °C ... 100 °C |
| Room temperature (service) | -40 °C ... 100 °C (depending of the capability curve of a load current/derating) |
Connection and method of connection
| Check connection | DIN EN 60998-2-2 (VDE 0613-2-2):2005-03 |
|---|---|
| The result of the test | Test approved |
| Checking of damage in the conductors and loosening | DIN EN 60998-2-2 (VDE 0613-2-2):2005-03 |
| Test approved |
Tensile test
| Tensile test | DIN EN 60998-2-2 (VDE 0613-2-2):2005-03 |
|---|---|
| Test approved | |
| Section of the driver / type of driver / traction force | 0,2 mm2 / stiff / > 10 N |
| 0,2 mm2 / flexible / > 10 N | |
| 4 mm2 / stiff / > 60 N | |
| 2.5 mm2 / flexible / > 50 N |
Electrical testing
| Rated | 24 To |
|---|---|
| Section of driver | 2.5 mm2 |
| Tension and sizing (III/2) | 400 V |
| Transient voltage design (III/2) | 4 kV |
Lines of flight and air spaces
| Air spaces and lines of flight | DIN EN 60664-1 (VDE 0110-1):2008-01 |
|---|---|
| Specification of the test | DIN EN 60664-1 (VDE 0110-1):2008-01 |
| Minimum value of air gap - field inhomogéneo (III/3) | 3 mm |
| Minimum value of air gap - field inhomogéneo (III/2) | 3 mm |
| Minimum value of air gap - field inhomogéneo (II/2) | 3 mm |
| Minimum value of the line of flight (III/3) | 3.2 mm |
| Minimum value of the line of flight (III/2) | 3 mm |
| Minimum value of the line of flight (II/2) | 3.2 mm |
Took place. calent.
| Result | Test approved |
|---|---|
| Specification of the test | DIN EN 60998-2-1 (VDE 0613-2-1):2005-03 |
Test vibration
| Specification of the test | DIN EN 60068-2-6:1996-05 |
|---|---|
| Result | Test approved |
| Frequency | 10 - 150 - 10 Hz |
| Sweep speed | 1 octave/min |
| Amplitude | 0.35 mm (10 - with 60.1 Hz) |
| Acceleration | 5 g (with 60.1 - 150 Hz) |
| Duration of test per axis | 2.5 h |
Resistance to aging, moisture and the penetration of solid objects
| Dry heat | 168 h/100 °C |
|---|---|
| Moist heat | 48 h/30 °C/92 % |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss
| eCl@ss 5.1 | Twenty seven million two hundred sixty one thousand one hundred |
|---|---|
| eCl@ss 6.0 | Twenty seven million two hundred sixty one thousand one hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand four hundred one |
UNSPSC
| UNSPSC 13.2 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
|---|---|
| UNSPSC 18.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 19.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 20.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 21.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
Datasheet - PDF
