SAMPLE DMC 0,5/ 4-G1-2,54 SMD
1859819
PHOENIX_CONTACT
5
PCB headers, nominal current: 6 A, rated voltage (III/2): 160 V, number of positions: 4, pitch: 2.54 mm, color: black, contact surface: Gold, mounting: SMD soldering
PCB headers, nominal current: 6 A, rated voltage (III/2): 160 V, nominal cross section: 0.5 mm², number of positions: 4, pitch: 2.54 mm, color: black, contact surface: Gold, mounting: SMD soldering, pin layout: Linear pad geometry, solder pin [P]: 2 mm
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Orderkey | 1859819 |
---|---|
Packing unit | 1 pc |
Minimum order quantity | 5 pc |
GTIN | 4055626113111 |
Weight per Piece (excluding packing) | 2.000 g |
Custom tariff number | 85366930 |
Country of origin | PL (Poland) |
Length [ l ] | 12.26 mm |
---|---|
Width | 10.66 mm |
Pitch | 2.54 mm |
Dimension a | 7.62 mm |
Width [ w ] | 10.66 mm |
Height [ h ] | 11.39 mm |
Height | 9.39 mm |
Length of the solder pin | 2 mm |
Pin dimensions | 0.64 x 0.64 mm |
Pin spacing | 2.54 mm |
Length | 12.26 mm |
Range of articles | DMC 0,5/..-G1-SMD |
---|---|
Insulating material group | IIIa |
Rated surge voltage (III/3) | 2.5 kV |
Rated surge voltage (III/2) | 2.5 kV |
Rated surge voltage (II/2) | 2.5 kV |
Rated voltage (III/3) | 32 V |
Rated voltage (III/2) | 160 V |
Rated voltage (II/2) | 160 V |
Connection in acc. with standard | EN-VDE |
Nominal current IN | 6 A |
Insulating material | LCP |
Flammability rating according to UL 94 | V0 |
Color | black |
Number of positions | 4 |
Connection in acc. with standard | EN-VDE |
---|---|
Flammability rating according to UL 94 | V0 |
China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
---|---|
No hazardous substances above threshold values |
eCl@ss 4.0 | 27260700 |
---|---|
eCl@ss 4.1 | 27260700 |
eCl@ss 5.0 | 27260700 |
eCl@ss 5.1 | 27260700 |
eCl@ss 6.0 | 27260700 |
eCl@ss 7.0 | 27440402 |
eCl@ss 8.0 | 27440402 |
eCl@ss 9.0 | 27440402 |
UNSPSC 13.2 | 39121409 |
---|---|
UNSPSC 18.0 | 39121409 |
UNSPSC 19.0 | 39121409 |
UNSPSC 20.0 | 39121409 |
UNSPSC 21.0 | 39121409 |
Title: | Size: | Type: |
---|---|---|
PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
