SACC-DSI-M12FS-4CON-M16/0,2 1497131 PHOENIX CONTACT Conect. plug. to be apar. wall poster., Universal, 4-pol..
SACC-DSI-M12FS-4CON-M16/0,2
1497131
PHOENIX_CONTACT
100
Conect. plug. to be apar. wall poster., Universal, 4-pole, Female connection, straight, M12-Standard, coding: A, free cable end, Rear wall mounting, M16 x 1.5, Single stranded wires, cable length: 0.2 m, 0.34 mm², TPE braided wire
Connect. plug. for apar. poster wall., Rear mount
Device connector, rear mounting, coding: A, on free cable end, Rear mounting, Individual wires
Connectors > Circular connector, mounting (with cable)
Field Device Connectors (FDC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| General | Lock nut is included in the scope of delivery |
| Mounting type | Rear mounting |
| Connection method | Individual wires |
| Product type | Circular connectors (device side) |
| Coding | A |
| Thread type | M12 |
| Conductor connection | |
| Connection method | Individual wires |
| Contact connection type | Socket |
| Connection 2 | |
| Head design | free cable end |
| Feature Name | Feature Value |
|---|---|
| Cable length (EF000536) | 0.2 mm |
| Type of plug-in contact, outer side (EF005528) | None |
| Mounting method (EF000003) | Back wall mounting |
| Housing material (EF001596) | Other |
| Material core insulation (EF000061) | Other |
| Material of contact surface (EF004020) | Other |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Ambient temperature (EF002386) | 85 °C |
| Operating temperature (EF002393) | -25 °C |
| Rated voltage (EF000228) | 250 V |
| With shield connection (EF002535) | No |
| Screw-in thread (EF012303) | M12 |
| Core cross section (EF000018) | 0.34 mm² |
| Min. number of insertion cycles (EF012212) | 100 |
| Degree of protection (IP), mounted (EF007466) | Other |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX CONNECTORS EN.pdf | 68 Mbytes |
|
