SAC-4P-M12MS/4,2-240 1548472 PHOENIX CONTACT Sensor/actuator cable, 4-pole, halogen-free PUR, irradiation cr..
SAC-4P-M12MS/4,2-240
1548472
PHOENIX_CONTACT
100
Product on demand only, returns will not be accepted.
Sensor/actuator cable, 4-pole, halogen-free PUR, irradiation cross-linked, orange RAL 2003, Straight M12 connector, coding: A, to free cable end, cable length: 4.2 m
Sensor/Actuator Cable, 4-Pole, Halogen-Free PUR, Yellow, M12 Straight Male Connector, Coding: A, To Free Cable End, Cable Length: 4.2 m
Sensor/Actuator Cable, Halogen-Free 4-Pole, M12 Straight Connector, Coding: A, Free Cable End, Cable Length: 4.2 m
Sensors > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| Product Type | Sensor/Actuator Cables |
| Number of poles | 4 |
| Number of Cable Outlets | 1 |
| Shielded | No |
| Codification | to |
| Insulation Properties | |
| Surge Category | Ii |
| Degree of pollution | 3 |
| Flammability class according to UL 94 | HB |
| Gasket material | NBR |
| Grip body material | Fire-resistant, self-extinguishing TPU |
| Contact material | CuSn |
| Material: Contact Surface | Ni/AU |
| Contact Support Material | TPU GF |
| Screw connection material | Zinc die-cast iron, nickel-plated |
| Nominal voltage UN | 250 V AC |
| 250 V DC | |
| Nominal Current IN | 4 A |
| Mechanical data | |
| Plug Cycles | ≥ 100 |
| Status Indication | No |
| Connection 1 | |
| Construction | M12 Straight Connector |
| Number of poles | 4 |
| Encoding Type | to |
| Connection 2 | |
| Construction | Free Cable End |
| Cable length | 4.2 m |
| Number of poles | 8 |
| Line Section | 8x 0.25 mm² |
| Outer Wrap, Material | PUR |
| Outer Wrap, Color | orange RAL 2003 |
| Environmental conditions | |
| Protection Index | IP65 |
| IP67 | |
| IP68 | |
| Ambient Temperature (Service) | -25 °C ... 90°C (male/female) |
| -40 °C ... 80°C (cable, fixed arrangement) | |
| -5 °C ... 80 °C (Cable, movable arrangement) | |
| Feature Name | Feature Value |
|---|---|
| Number of poles (EF001391) | 4 |
| Type of electrical connection, field-sided (EF005525) | M12 |
| Type of plug-in contact, field sided (EF006269) | Male (plug) |
| Positioning cable feed, field-sided (EF005928) | Straight |
| Type of electrical connection, box-sided (EF005524) | Other |
| Positioning cable feed, box-sided (EF005927) | Other |
| Cable length (EF000536) | 4.2 m |
| Material of cable sheath (EF004136) | Other |
| Halogen free (EF000025) | No |
| Colour cable sheath (EF008249) | Other |
| With LED indication (EF005950) | No |
| Screened (EF000881) | No |
| Cable type (EF000081) | Multi-core |
| Vulcanize (EF004115) | No |
| Material contact body (EF008248) | CuSn |
| Material of contact surface (EF004020) | Other |
| Rated current In (EF008250) | 4 A |
| Rated voltage (EF000228) | 250 V |
| Degree of protection (IP) (EF005474) | IP65 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX CONNECTORS EN.pdf | 57 Mbytes |
|
