SAC-4P-M12MS/20,0-BF145 1417626 PHOENIX CONTACT Sensor/actuator cable SAC-4P-M12MS/20,0-BF145 1417626
SAC-4P-M12MS/20,0-BF145
1417626
PHOENIX_CONTACT
50
Product on demand only, returns will not be accepted.
Sensor/actuator cable - SAC-4P-M12MS/20,0-BF145 - 1417626
Sensor/actuator cable, 4 poles, BETAFLAM 145, RAL7021 black grey, straight M12 connector, A-coated, free cable end, cable length: 20m
Sensors > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Sensor/actuator cable, 4-pos., BETAFLAM 145, RAL 7021 (black gray), straight M12 connector (A-coded) to free cable end, cable length: 20 m
Key Commercial Data
| Orderkey | 1417626 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626117737 |
| Custom tariff number | 85444290 |
Ambient conditions
| Degree of protection | IP65 |
|---|---|
| IP67 |
General
| Rated current at 40°C | 4 A |
|---|---|
| Rated voltage | 250 V AC |
| 250 V DC | |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Torque | 0.4 Nm |
Classifications
eCl@ss
| eCl@ss 5.1 | 27061801 |
|---|---|
| eCl@ss 6.0 | 27279200 |
| eCl@ss 7.0 | 27279218 |
| eCl@ss 8.0 | 27279218 |
| eCl@ss 9.0 | 27060311 |
ETIM
| ETIM 5.0 | EC001855 |
|---|---|
| ETIM 6.0 | EC001855 |
| ETIM 7.0 | EC001855 |
UNSPSC
| UNSPSC 13.2 | 31251501 |
|---|
| Feature Name | Feature Value |
|---|---|
| Type of electrical connection, field-sided (EF005525) | M12 |
| Type of plug-in contact, field sided (EF006269) | Male (plug) |
| Positioning cable feed, field-sided (EF005928) | Straight |
| Type of electrical connection, box-sided (EF005524) | Other |
| Positioning cable feed, box-sided (EF005927) | Other |
| Cable length (EF000536) | 20 m |
| Material of cable sheath (EF004136) | Other |
| Halogen free (EF000025) | Yes |
| Colour cable sheath (EF008249) | Other |
| With LED indication (EF005950) | No |
| Screened (EF000881) | No |
| Cable type (EF000081) | Multi-core |
| Vulcanize (EF004115) | Yes |
| Material contact body (EF008248) | CuSn |
| Material of contact surface (EF004020) | Other |
| Permitted cable outer temperature after assembling without vibration (EF001686) | -55 °C |
| Permitted cable outer temperature during assembling/handling (EF001685) | -35 °C |
| Rated current In (EF008250) | 4 A |
| Rated voltage (EF000228) | 250 V |
| Degree of protection (IP) (EF005474) | IP65 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX CONNECTORS EN.pdf | 57 Mbytes |
|
